Lilliput Q7 Pro 7 HDR and LUT Monitor with HDMI/SDI Conversion Q7 PRO

The Q7 Pro 7" HDR and LUT Monitor from Lilliput is a broadcast monitor for professional camera and video applications. It offers a 1920 x 1200 resolution, 500 cd/m² brightness, and 1000:1 contrast ratio. The HDMI connector can actively transmit an HDMI input signal, or output an HDMI signal that has been converted from SDI.

The Q7 Pro features adjustable color space and accurate color calibration, providing clear and vivid images. The HDR feature reproduces a wide dynamic range of luminosity, which allows lighter/darker details to be displayed more clearly. You can select the appropriate gamma mode once the HDR feature is off. The built-in 3D LUT allows for a wide color gamut range and features eight default logs and six user logs. The 3D LUT Load supports the  loading of .cube files via a USB flash drive.

The Q7 Pro provides an array of auxiliary functions designed for improving your photos and movies. These include color space, HDR, timecode, YRGB column, pixel zoom, vectorscope, waveform, audio level meter, peaking, false color, histogram, exposure, check field, color bars, and image flip functions. The F1 and F2 user-definable buttons allow you to customize the auxiliary function shortcuts, and the 75mm VESA and 1/4"-20 shoe mount allow you to mount the Q7 Pro on your DSLR or camcorder.

Features

• Display: 7 inch
• 1920x1200，1000:1，500cd/m2
• Interface: HDMI, 3G-SDI
• SDI and HDMI cross conversion
• Adjustable color space: Native, SMPTE-C, Rec.709, and EBU
• Color calibration supports the PRO/LTE version of Lightspace CMS by Light Illusion
• HDR, Gamma, 3D LUT(LOGS)
• SDI and HDMI cross conversion
• Full-screen Waveform




• 12V DC Adapter
• Sunshade
• HDMI A/C cable
• Shoe mount
• VESA Battery Bracket
• Battery Plate
• VESA mount plate
• Manual
