Guide Thermal Imaging Rifle Scope TU430

The Guide TU430 is a thermal riflescope for medium and long distances and has the exact same design as optical riflescopes. This thermal scope has a 400x300 VOx detector (17μm), a 35mm objective lens and a zoom range of 2.3 to 9.2x. The Guide TU430 can detect a car at 2,4 km and a person at 1 km. On the housing itself you can easily store 10 different zero profiles. With this Guide TU430 you have the best balance between field of view and viewing distance.

Properties of the thermal image

• 400x300 VOx detector (pixel size 17μm)
• 50hz refresh rate (real-time image)
• Projected onto 0.39" OLED display (1024x768)
• Different color palettes, including White/Black/Red/Green Hot
• Thermal image does not depend on the weather, you also have image during e.g. fog and rain
• Detection distance: 2.4km (car) and 1 km (person)
• Field of view: 11,1 x 8,3 degrees

Properties of the reticle

• Choice of 10 different reticles
• Reticle available in 6 different colors and 10 levels of brightness
• Reticle magnifies with the zoom, similar to First Focal Plane of optical rifle scopes
• Save 10 zero profiles to use the rifle scope directly on different weapons without having to shoot again
• Zero calibration distances: 50 / 100 / 200 / 300 / 500m
• Easy manual elevation / width adjustment on the body

Attaching the scope to your weapon

• Universal 30mm tube
• With the help of 30mm mounting rings easy to use on many weapons
• Mountings can be found under "optional accessories" or via this link
• For Weaver/Picatinny, Dovetail (air gun) etc.

Useful functions

• Hot Track function, where animals / people with cursor are directly "pointed" at
• Stadiametric range finder (calculates the approximate distance to an animal or person)
• Picture-in-Picture mode to further magnify a small part of the image
• Wi-fi and Bluetooth to share and view recordings
• When a smartphone/tablet is connected to the scope, someone else can enjoy everything that you see
• Free app (iOS and Android)

User convenience

• Shock resistance: 500G/1ms
• IP67 certified: waterproof, dustproof and shockproof
• Ultra-long operating time of up to 10 hours using only one 18650 battery (charger + battery included)
• Weighs only 940 grams
• USB-C connection (cable included)
• Certifications: RoHS, CE, FCC, EAC, UN38.3 (battery certificate)

Application Guide TU430

This riflescope is made to shoot with extreme precision at medium and long distances. Popular applications for this are hunting and tactical. The advantage of thermal imaging is that you have image anytime, anywhere and are not dependent on weather conditions. With thermal imaging, animals can never hide because their body heat makes them light up immediately on the display of your viewer. Even when they are behind bushes that you cannot see through with your own eye. You can use the Guide TU430 at night, in twilight and also during the day. Because you can set/save 10 zero profiles you can easily switch between different weapons.

The Guide TU series consists of three models. In the overview below we have elaborated what differences there are within the series. Do you have any questions? Please contact us.
