DJI Ronin-MX 3-axis stabiliser

The Ronin-MX from DJI is dual-use gimbal suitable both for mounting on the Matrice 600 aerial platform as well as deployment closer to the ground. Improving over the Ronin-M, it features magnesium construction to yield high rigidity while keeping the weight down. The gimbal is suitable for cinema cameras, mirrorless cameras, and DSLRs weighing up to 10 pounds. Out of the box it supports two-operator operation, and includes a radio controller (transmitter) for the camera operator. There is also an optional Thumb Controller (available separately) for solo operation. When installed on the Matrice 600 aircraft, the gimbal can be controlled via the DJI GO app. An included universal mounting adapter allows it to be adapted for use with jibs, car mounts, and various other types of camera support equipment. There is also a handlebar for handheld use.
Built to Perform
Designed to resist high G-forces using powerful motors and IMUs, the Ronin-MX is engineered to maintain stability and hold horizon when mounted to an aircraft or a vehicle. When mounted to the Matrice 600 aerial system, it communicates directly with DJI's flight controller. When attached to vehicles, it connects to an optional GPS module that allows it to stabilize actively for a smoother shot
360° Freedom of Movement
A slip ring allows the Ronin-MX to rotate 360° continuously when mounted to aircraft or vehicles, opening up more creative options. This is further enhanced by an increase in tilt-axis range (compared to the Ronin-M) from 90° straight down and beyond to 135°. Popular features of the Ronin series, such as the three modes of operation and SmoothTrack, are also present, giving film makers a range of creative angles and movements
Wireless Control and Transmission
The Ronin-MX is compatible with Lightbridge 2, providing long-range HD video transmission from the air to the ground from up to 3.1 miles away. If combined with the separately available DJI Focus and Focus Expansion Module, focus or aperture can also be pulled remotely with a twist of the wrist. An optional Remote Start/Stop add-on provides the ability to control shooting on a range of airborne cameras
App Control
Using DJI Assistant and the dedicated Assistant app for iOS and Android allows complete customization of the Ronin-MX and its behavior. If connected to Lightbridge 2, the DJI GO app can be used to control the gimbal and see an HD live feed from the camera
System Design
Refined Balance
A redesigned structure moves the Ronin-MX battery from the back to the front. This centers the weight of the camera, minimizing instability when flying directly forwards. It also dramatically increases the Ronin's agility and ability to handle rapid movements or high-G situations
Magnesium Construction
Built extensively of lightweight magnesium, the Ronin-MX weighs just 6.1 lb. This lightness allows it to be mounted to the Matrice 600, even when equipped with cameras as advanced as the RED EPIC, and to vehicles, with a minimum impact on vehicle handling
Power
Strengthened Motors and ESCs
A combination of stronger motors and ESCs makes the Ronin-MX 50% more powerful than the Ronin-M. This additional stiffness and power allows the system to better withstand wind resistance, when mounted to moving vehicles and aircraft, as well as more rapid movements
External Camera Battery
Cameras such as the RED EPIC need an external battery for power. A dedicated position designed for an optional battery plate provides an easy, cable-free mounting point for a second DJI Intelligent Battery. This provides two 12V D-Tap power sources for powering cameras and accessories
Intelligent Batteries
Ronin-MX batteries offer a battery life of up to three hours. Over-charge and over-depletion protection are built in, as is individual cell charge balancing. Remaining power is shown by clear LEDs and in the DJI GO app
Built-In Power Distribution
A dedicated power distribution box keeps wiring to a minimum while providing power to essential accessories. Two regulated 12V D-Taps, one 500mAh full-size USB connector, and a DJI Lightbridge connector enable connectivity and power to nearly everything a filmmaker might need
Control
Solo Mode with Optional Thumb Controller
The separately available Ronin Wireless Thumb Controller makes controlling the Ronin-MX easy and intuitive, enabling the capture of shots that would otherwise be impossible for a single operator
Second Operator Control
A wireless 2.4 GHz remote controller is included with the Ronin-MX enabling a second operator to remotely control pan, tilt, roll, and other functions
Three Operation Modes
Upright Operation Mode
Upright Mode allows the gimbal to be flipped over so the camera can be operated closer to eye level without straining to lift the gimbal. This can be used in various situations, such mounting on the top of the vehicle

Underslung (Suspended) Operation Mode
Suspended Operation Mode is the standard operation mode for Ronin-M. Low slung, close to the ground, or simply holding the gimbal in front of you offers stabilized handheld footage. This mode would also be used when mounted the gimbal on a flying platform such as a multirotor RC helicopter

Briefcase Mode
When a slimmer gimbal profile is needed – such as when moving through doorways or narrow paths – Briefcase Mode is ideal. It allows the gimbal to be held to the side and close to the legs, much like a briefcase
Additional Features
SmoothTrack Technology
Even with only one operator, SmoothTrack technology is designed to ensure the Ronin-MX translates movements into smooth camera angle changes. SmoothTrack settings, from speed to deadband to acceleration, are fully customizable. A "Single Axis Follow Mode" enables two axes to be locked while SmoothTrack guides the camera along only one axis of motion
Universal Mounting
Mount the Ronin-MX to aircraft using a specially designed mounting plate. A separate universal Quick Release system that doubles as a vibration-dampening system allows the Ronin-MX to be connected to everything from jib to tripod and anything in between. This plate isolates the Ronin-MX from unwanted vibrations coming from the platforms it is mounted to
Short Range Wireless Transmission
On the ground, the separately available SRW-60G allows film makers to see the image from the camera without running cables up the Ronin-MX
DJI Ronin-MX – универсальный подвес камеры
DJI Ronin-MX, первый универсальный воздушный подвес, объединяющий в себе одновременно электронный стедикам и подвес для мультикоптера, способный взаимодействовать бортовым полетным контроллером и нести видеокамеры весом до 4.5 кг.

Ронин MX сконструирован для ряда передовых фотокамер, использующихся во всем мире и полностью соответствует требованиям современной кинематографии: быстрое переключение конфигураций, плавность движения, быстрая балансировка и бесшумные моторы.

Для того, чтобы начать снимать профессионально, готовое видео в течение пяти минут, достаточно подключить видеокамеру к DJI Ronin-MX, сбалансировать его и нажать кнопку. Модернизированная Автоматическая настройка стабильности завершит настройку и балансировку без дополнительных инструментов.

Ключевые особенности

• Универсальный подвес с возможностью связи с бортовым полетным контроллером
• Возможность использования и в воздухе с DJI Matrice 600, и на земле
• Поддержка аксессуаров для дистанционной регулировки фокуса и диафрагмы
• Дистанционное управление и передача видео
• Ручные режимы работы: подвеса, вертикальный и портфель
• Возможность установки на краны
• Панорамирование на 360 градусов и наклон в диапазоне от +45 до -135 градусов
• Возможность передачи онлайн видео при помощи дополнительного оборудования
• Максимальная нагрузка 4.5 кг
• Поддержка кинокамер Black Magic, Canon, Panasonic, RED, Sony и Nikon

Усовершенствованный баланс
В переработанном конструктиве Ronin-MX, батарея сдвинута от задней части в направлении к передней, это сместило вес камеры к центру и свело к минимуму нестабильность при движении прямо вперед. Плюс это значительно увеличило маневренность и способность MX справляться с быстрыми движениями при высоких нагрузках.

Корпус из магниевого сплава
Будучи сконструированным из легкого магниевого сплава, DJI Ronin-MX весит всего 2.77 кг. Эта особенность позволяет устанавливать его на Мatrice 600, и оборудовать такими тяжелыми видеокамерами, как RED EPIC при минимальном влиянии на управляемость мультикоптера.

Более мощные моторы и регуляторы
Новые регуляторы оборотов и электродвигатели увеличивают мощность Ronin-MX, по сравнению с Ронин-М, на 50%. Дополнительная мощность и лучшее удержание позволяют лучше выдерживать сопротивление ветра при креплении на движущихся объектах и увеличивают скорость отклика.

Внешняя батарея камеры
Некоторые видеокамеры, например, как RED требуют внешнего аккумулятора для своего питания. Поэтому для установки дополнительного аккумулятора предусмотрена отдельная пластина в специально предназначенном для этого месте, обеспечивающем простое беспроводное подключение для второй батареи. Это добавляет два дополнительных 12V P-tap порта для питания видеокамер и аксессуаров.

Интеллектуальные батареи
Умные аккумуляторы DJI Ronin-MX отличаются компактностью, малым весом и обеспечивают время работы до 3 часов. Комплект из нескольких аккумуляторов доводит день съемок до полного.

Аккумуляторы защищены от перезаряда и переразряда, а отдельные ячейки балансируются при заряде. Оставшаяся емкость отображается на светодиодах аккумуляторов и в приложении DJI Go.

Мощность и точность
Благодаря мощным моторам и способности выдерживать высокие перегрузки, Ronin-MX охраняет стабильность и с легкостью удерживает свое положение при установке на движущийся объект, самолет или автомобиль.

Бесколлекторные моторы настолько точны, что удерживают и поворачивают подвес в пределах ±0.02°.

При установке на полетную платформу М600, MX взаимодействует непосредственно с контроллером гексакоптера, связанным с модулем GPS, который стабилизирует его положение, обеспечивая плавность съемки.

Свобода движения
Скользящее контактное кольцо позволяет DJI Ronin-MX непрерывно вращаться на всем диапазоне 360°, а ход по оси наклона простирается от 90° вертикально вниз и далее вверх на 135°.

Универсальное крепление
Крепление Ronin-MX, выполняет двойную функцию, оно не только сконструировано для того, чтобы легко и быстро снимать и устанавливать подвес на стрелы, штативы или летающие платформы, но и изолирует Ronin-MX от нежелательных вибраций, потому его можно использовать везде.

Беспроводное управление и передача сигнала
Ронин-MX совместим с Lightbridge 2, что гарантирует дальнюю передачу HD-видео с воздуха на землю на удалении до 5 км.

В комбинации с системой фокусировки DJI Focus и модулями расширения Focus Expansion Module, добавляется возможность удаленной фокусировки и изменения диафрагмы, простым поворотом запястья.

Дополнительная установка Дистанционного модуля запуска/остановки дает возможность управлять видеосъемкой с нескольких бортовых камер.

Управление DJI Ronin-MX
1. Комплексное - Используя приложения DJI Assistant для iOS и Android, возможно полностью настроить Ронин-MX под себя при работе в различных режимах.

При подключении к Lightbridge 2, DJI Assistant позволяет управлять гексакоптером М600 в полете, в различных Интеллектуальных Режимах полета, режимах дистанционного управления, перемещая подвес и просматривая видео в HD формате с камеры.

2. Самостоятельное - Будучи простым в настройке, при помощи беспроводного контроллера DJI Ronin, управление Ronin-MX становится настолько простым и интуитивным, что позволяет осуществлять съемку одним оператором.

3. Двумя операторами - Пульт дистанционного управления на 2.4 ГГц, идущий в комплекте с МХ, позволяет подключить к видеосъемке 2-го оператора для дистанционного управления панорамированием, наклоном, креном и другими функциями.

Режимы работы
Классические три режима работы, характерные для всей линейки Ронин, делают DJI Ronin-MX удобной и гибко настраиваемой системой стабилизации камеры:

1. Подвеса - самый распространенный режим съемки, когда МХ удерживается прямо перед пользователем
2. Вертикальный – перевернутый режим подвеса, помещающий камеру выше, что оптимально для съемки поверх толпы, препятствий или открытые люки.
3. Портфеля – сужает платформу, и она легко проходит через узкие коридоры и двери.

DJI Ronin-MX 3-Axis Stabilized Handheld Gimbal System

Cinematic film making demands rapid setup and a host of camera configurations. The Ronin-MX has been designed to carry many of the cameras used every day on sets worldwide, and SmoothTrack™ algorithms ensure movements are smooth in every configuration.

A repositioned battery improves balance while stability is enhanced by a camera cage that locks mounted cameras in place at the top and at the bottom. Silent motors prevent on set mics picking up motor noise.

Powerful and Accurate
Designed to resist high G-forces using powerful motors and IMUs, the Ronin-MX is engineered to maintain stability and hold horizon when mounted to an aircraft or a vehicle. When mounted to the M600 aerial system, it communicates directly with DJI’s flight controller and when attached to vehicles, it connects to an optional GPS module allowing it to stabilize actively for a smoother shot.

Freedom to Move
A slip ring allows the Ronin-MX to rotate 360° continuously when mounted to aircraft or vehicles, opening up more creative options. This is further enhanced by an increase in tilt axis range from 90° straight down and beyond to 135°. Popular features of the Ronin series such as the three modes of operation and SmoothTrack™ are also present, giving film makers a range of creative angles and movements.

Wireless Control and Transmission
The Ronin-MX is compatible with Lightbridge 2, providing long-range HD video transmission from the air to the ground from up to 3.1miles (5km) away. If combined with the optional DJI Focus and Focus Expansion Module, focus or aperture can also be pulled remotely with a twist of the wrist. An optional Remote Start/Stop add-on provides the ability to control shooting on a range of airborne cameras.

Comprehensive App Control
Using DJI Assistant and the dedicated Assistant app for iOS and Android allows complete customization of the Ronin-MX and its behavior. If connected to Lightbridge 2, the DJI GO app can be used to control how the M600 flies including Intelligent Flight Modes, remote control modes, move the gimbal and see an HD live feed from the camera.

Refined Balance
A redesigned structure moves the Ronin-MX battery from the back to the front. This centers the weight of the camera, minimizing instability when flying directly forwards. It also dramatically increases the Ronin’s agility and ability to handle rapid movements or high-G situations.

Magnesium Construction
Built extensively of lightweight magnesium, the Ronin-MX weighs just 6.11lb (2.77kg). This lightness allows it to be mounted to the M600 even when equipped with cameras as advanced as the RED EPIC, and to vehicles with a minimum impact on vehicle handling.

Strengthened Motors and ESCs
A combination of stronger motors and ESCs makes the Ronin-MX 50% more powerful than the Ronin-M. This additional stiffness and power allows the system to better withstand wind resistance when mounted to moving vehicles and aircraft, as well as more rapid movements.

External Camera Battery
Cameras such as the RED EPIC need an external battery for power. A dedicated position designed for an optional battery plate provides an easy, cable free mounting point for a 2nd DJI Intelligent Battery. This provides two 12V P-tap power sources for powering cameras and accessories.

Intelligent Batteries
Intelligent Ronin-MX batteries are compact, light and offer a long battery life of 3 hours. Multiple batteries can be easily brought to set for a full day of filming. Over-charge and over-depletion protection is built in, as is individual cell charge balancing. Remaining power is shown by clear LEDs and in the DJI GO app.

Remote Focus Control
The DJI Focus uses DJI’s expertise in brushless motors for previously unheard of levels of precision and accuracy. The brushless motor puts just ±0.02 of accuracy in the hand so that turning the remote is just like turning the lens itself. It also features high torque and a fast reaction speed so that subjects can be kept in focus no matter how they move. When upgraded with a Focus Expansion Module, the Focus can control aperture or focus across Lightbridge 2’s 3.1miles (5km) range.

Precision Solo Camera Control
Simple to set up and use, the DJI Ronin Wireless Thumb Controller makes controlling the Ronin-MX easy and intuitive, enabling the capture of shots that would otherwise be impossible for a single operator.

2nd Operator Control
A wireless 2.4GHz remote controller is included with the Ronin-MX enabling a 2nd operator to remotely control pan, tilt, roll, and other functions. By using the optional Lightbridge 2 Remote Controller, you have long range control of the Ronin-MX up to 3.1 miles (5km).
A wireless 2.4GHz remote controller is included with the Ronin-MX enabling a 2nd operator to remotely control pan, tilt, roll, and other functions. By using the optional Lightbridge 2 Remote Controller, you have long range control of the Ronin-MX up to 3.1 miles (5km).

Delivery Contents:
Gimbal x1
Handle Bar x1
Remote Control – 2.4 GHz x1
Tuning Stand x1
Charger x1
DJI Intelligent Battery x2
Cable Pack x1
Micro USB Cable x1
Camera Mounting Plate x1
Upper Mounting Plate x1
Vibration Absorber X1

Accessories Package
Camera Screw A (1/4”) x2
Camera Screw B (3/8”) x2
Camera Screw C (1/4”) x2
Camera Screw D (3/8”) x2
Lens Support Screw x1
Lens Support x1
Allen Wrench x4 (2 mm, 3 mm, 4mm, 3/16”)

GENERAL



Built-In Functions

Operation Modes
-Underslung Mode
-Upright Mode
-Briefcase Mode
-Aerial Mode
-Jib or Wirecam Mode
Built-in, independent IMU module
DJI Specialized Gimbal Drive Motors with Encoders
Bluetooth Module
USB Connection
2.4GHz Receiver
Temperature Sensor
DJI Advanced 32-Bit DSP Processor
D-Bus Receiver Supported

MECHANICAL & ELECTRICAL CHARACTERISTICS



Working Current

Static current: 300mA (@16V); Dynamic current: 600mA (@16V)
Locked motor current: Max 10A (@16V)

Operating Temperature

5° F ~ 120° F (-15° C ~ 50° C)

Weight

Including handle bar: 6.11 lb (2.77 kg); including vibration absorber, without handle bar: 4.74 lb (2.15 kg)

Gimbal Dimensions

Excluding handle bar: 280 mm (W) × 370 mm (D)x 340 mm (H); including handle bar: 560 mm (W) × 370 mm (D) × 440 mm (H)

PERIPHERAL



Camera Tray Dimensions

Maximum depth from the center of gravity on camera base plate: 120mm
Maximum height measured from top of camera base plate: 195mm
Maximum width: 160mm

Accessory Power Connections

12V Regulated P-Tap × 2, USB 500mW × 1, DJI Lightbridge × 1

GCU Input Power

4S Ronin-M Battery

Connections

2.4GHz Remote Controller, Bluetooth 4.0, USB 2.0

PC Assistant Software Requirements

Windows XP or above; Mac OS X 10.9 or above

Mobile Assistant Software Requirements

iOS 7.1 or above; Android 4.3 or above

WORKING PERFORMANCE



Load Weight (Reference Value)

10 lb (4.5 kg)

Angular Vibration Range

± 0.02°

Maximum Controlled Rotation Speed

Pan axis: 200°/s; Tilt axis: 100°/s

Roll axis: 30°/s

Mechanical Endpoint Range

Pan axis control: 360°; Tilt axis control: +270° to -150°; Roll axis control: ± 110°

Controlled Rotation Range

Pan axis control: 360°; Tilt axis control: +45° to -135°; Roll axis control: ± 25°
