FNIRSI DWS-200 200W Soldering Station

FNIRSI DWS-200 200W Soldering Station

The FNIRSI DWS-200 soldering station is engineered for precise and comfortable soldering, suitable for both simple repairs and demanding electronics projects. It features a maximum power output of 200 W, instant heating capability, intelligent temperature stabilization, and a wide range of adjustable settings. The station includes a clear 2.8-inch color HD TFT screen, the ability to save frequently used temperature presets, and safety features that extend the equipment's lifespan. A multifunctional stand with an automatic soldering iron sleep mode enhances usability and energy efficiency.

High Power and Instant Heating

Equipped with a high-performance pure copper transformer, the station operates stably with an input voltage range of 100 to 240 V AC. It delivers up to 200 W of power, heating the soldering iron in approximately 1 second and melting solder in about 3 seconds. The temperature can be precisely adjusted from 10060C to 45060C (2126F to 8426F), with the option to switch between Celsius and Fahrenheit units to suit user preferences.

Intelligent Temperature Control

The station uses a PID algorithm for temperature stabilization, maintaining the set temperature during operation. It offers three factory-set temperature presets at 15060C, 33060C, and 45060C for quick switching. Compatibility with F210 and F245 soldering tips allows adaptation to various soldering tasks.

Easy-to-Read Screen and Parameter Preview

The 2.8-inch color HD TFT display provides clear access to key information. Users can select from three display modes: a classic temperature readout, a dynamic temperature graph, or a combined view. The dynamic temperature curve feature enables real-time monitoring of temperature changes during soldering.

Work Comfort and Effective Protection

The station includes an inductive standby mode activated by the multifunctional soldering iron stand. When the iron is placed in the holder, the device automatically enters sleep mode, reducing energy consumption and prolonging tip life. Safety features include antistatic protection and short-circuit protection, ensuring safety for both the user and electronic components.

Included in the Set

• FNIRSI DWS-200 200W Soldering Station
• Soldering iron stand
• F245 handle
• F210 holder
• 9 soldering tips (B, KU, K, C2, I, JS for F245; K, I, IS for F210)
• 2 auxiliary holders
• Power cord
• Connection cable
• User manual

Technical Specifications

• Manufacturer: FNIRSI
• Model: DWS-200
• Display: 2.8-inch TFT color screen
• Temperature range: 10060C to 45060C (2126F to 8426F)
• Peak power: 200 W (maximum)
• Input voltage: 100 V to 240 V AC
• Input fuse: 3 A
• Compatible tip types: F210, F245
• Dimensions: 156 d7 96 d7 103 mm
• Weight: 475 g (main unit only)
