Canare L-2E5 is our Miniature version of L-2T2S when small size and light weight is a consideration. Useful for patch cables, hidden lavaliere microphones or any balanced audio installation.
Canare L-2E5 is our Miniature version of L-2T2S when small size and light weight is a consideration. Useful for patch cables, hidden lavaliere microphones or any balanced audio installation.
Applications:
- Microphones
- Portable Applications
- Audio Patch Cords
- PA Systems
Features:
- Braided Copper Shield
- Flexible in Extreme Cold Weather
- Reduced Handling Noise
- Rejects EMI and RFI
| Model | Std. Lng. ft. (m) | Wt Std. Lng. lbs (kgs) | Nom. O.D. in. (mm) | Jacket Nom. Thick. in. (mm) | Brittle Point F° (C°) | No. of Cond. | Insul. Type* Thick mil | Cond-AWG (Qty./mil) Cross Sec. Area mil.? | Pitch Twist Quad in. (mm) | Shield |
| L-2E5 | 656 (200) | 20.2 (9) | .181 (4.6) | .035 (0.9) | -56 (-49) | 2 | IPE | AC - #26 (30/3.15) 322.5 | <0.79 (-) | >96.7% TAC Braid |
*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
**Effective AWG of combined twin conductors.
**Effective AWG of combined twin conductors.
| Model | Cond. D.C.R. ohm/1000ft (ohm/100m) | Shield D.C.R. ohm/1000ft (ohm/100m) | Nom. Cap. *** pF/m | Nom. Cap. † pF/m | Nom. Imp. ohm | Nom. Atten. V/1000ft (V/100m) | Group Delay Time nS/ft (nS/m) |
| L-2E5 | <38.7 (<12.7) | <6.7 (<2.2) | - | - | - | - | - |
***Capacitance between conductors.
†Capacitance between conductors to shield.
†Capacitance between conductors to shield.
