MagicSoft Playout ver 8 HD 1 Channel
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Video Mixer |
| Connector | 3,5mm |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
MagicSoft Playout Broadcast Automation Software
MagicSoft Playout software is an intuitive and powerful multi-format playout solution designed for professional environments such as broadcasting stations and production studios. It supports 24/7 playout for news, music, and movie channels, enabling commercial insertion and switching between multiple live video sources. Compatible with Windows 7, 8, 10, and equivalent 64-bit Windows Server OS.
Media Compatibility
Accepts media files ranging from 8K (7680 x 4320) down to 320 x 240 resolution, with frame rates between 3 and 120 fps.
Supported Live Inputs and Outputs
- BlackmagicDesign devices (Decklink & Intensity)
- NDI streams
- UDP streams
Output streaming supports resolutions from 4K down to 360 x 288.
Streaming Servers Supported
Compatible with RTMP/RTMPS servers for 24/7 streaming including YouTube, Twitch, Wowza, Vimeo, Facebook, and DaCast. Also supports UDP streaming (unicast and multicast) using H264 with AAC, AC3, or MP2 audio codecs.
Video Input and Output Modes
- 4K UHD: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps
- HD1080p: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps
- HD1080i: 50 / 59.94 fps
- HD720p: 50 / 59.94 fps
- SD: PAL / NTSC
The internal video engine automatically resizes, matches aspect ratio, and transcodes media files and live inputs to match output characteristics.
Video Inputs and Outputs
Supports up to 4 video inputs and 4 video outputs depending on device capabilities, including:
- SDI with embedded audio
- SDI with AES audio
- YUV with analog audio
- Composite with analog audio
- HDMI
Scheduling and Playback
The MagicSoft Playout client allows scheduling clips or live inputs to start at predefined times. Skipped events or gaps are clearly marked.
Advanced Audio Module
- Supports up to 16 audio output channels
- Real-time audio loudness normalization (EBU, NTSC, YouTube, or custom settings)
This module enables media playback without manual sound level adjustments, providing real-time automatic processing without compression or distortion. It achieves predictable loudness levels, preserves high dynamic range audio quality, and prevents signal clipping.
Conformance Recorder Module
Allows recording of the playout output with support for two simultaneous profiles.
Timeline and Editing Features
- Flexible, intuitive timeline with scrubbing, marking, and segment display
- Shows continuity or overlapping of segments
- Supports multiple consecutive rows selection and collapsible grouping with multi-level grouping
- Trimming feature for easy segment creation and property management
Supported Video Codecs and Containers
- H264 AVC Intra 50 and AVC Intra 100 (.mxf)
- H264 8-bit and 10-bit (.mp4, .mov, .avi, .mkv, transport stream; 4:2:0 and 4:2:2)
- HEVC 8-bit and 10-bit (.mp4, .mov, .avi, .mkv, transport stream; 4:2:0 and 4:2:2)
- XdCAM 35 and XdCAM 50 (.mov and .mxf)
- ProRes (.mov)
- DNxHD 8-bit and 10-bit (.mov and .mxf)
- DNxHR (.mov and .mxf)
- MPEG2 program stream and transport stream (4:2:0 and 4:2:2)
- DV (.avi, .mov, .mxf, rawDV)
- DVCPRO (.avi and .mov)
- DVCPRO HD (.mov)
