MagicSoft Playout ver 8 SD with 2 ch MSPLAY8SD2CH

MagicSoft Playout Broadcast Automation Software

MagicSoft Playout software is an intuitive and powerful multi-format playout solution designed for professional environments such as broadcasting stations and production studios. It supports 24/7 playout for news, music, and movie channels, enabling commercial insertion and switching between multiple live video sources. Compatible with Windows 7, 8, 10, and equivalent 64-bit Windows Server OS.

Media Compatibility

Accepts any media file size from 320 x 240 up to 8K (7680 x 4320) resolution, with frame rates ranging from 3 to 120 fps.

Supported Live Inputs and Outputs

• BlackmagicDesign devices (Decklink & Intensity)
• NDI streams
• UDP streams

Output streaming supports resolutions from 360 x 288 up to 4K.

Streaming Servers Supported

• YouTube
• Twitch
• Wowza
• Vimeo
• Facebook
• DaCast

UDP streaming supports unicast and multicast using H264 with AAC, AC3, or MP2 audio codecs.

Video Input and Output Modes

• 4K UHD: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps
• HD 1080p: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps
• HD 1080i: 50 / 59.94 fps
• HD 720p: 50 / 59.94 fps
• SD: PAL / NTSC

The internal video engine automatically resizes, matches aspect ratio, and transcodes media files and live inputs to match output characteristics.

Video Inputs and Outputs

Supports up to 4 video inputs and 4 video outputs depending on device capabilities, including:

• SDI with embedded audio
• SDI with AES audio
• YUV with analog audio
• Composite with analog audio
• HDMI

Scheduling and Timeline Features

The MagicSoft Playout client allows scheduling clips or live inputs to start at predefined times. Skipped events or gaps are clearly marked. The timeline is flexible and intuitive, supporting scrubbing, marking, segment display, continuity, and overlapping segments. Multiple consecutive rows can be grouped and collapsed, with support for multi-level grouping. The trimming feature enables easy segment creation and property management.

Advanced Audio Module

• Supports up to 16 audio output channels
• Real-time audio loudness normalization (EBU, NTSC, YouTube, or custom settings)

This module allows media playback without manual sound level adjustments, providing real-time automatic processing without compression or distortion. It achieves predictable loudness levels, preserves high dynamic range audio quality, and prevents signal clipping.

Conformance Recorder Module

Enables recording of the playout output with support for two simultaneous profiles.

Supported Video Codecs and Containers

• H264 AVC Intra 50 and AVC Intra 100 (.mxf)
• H264 8-bit and 10-bit (.mp4, .mov, .avi, .mkv, transport stream; 4:2:0 and 4:2:2)
• HEVC 8-bit and 10-bit (.mp4, .mov, .avi, .mkv, transport stream; 4:2:0 and 4:2:2)
• XdCAM 35 and XdCAM 50 (.mov and .mxf)
• ProRes (.mov)
• DNxHD 8-bit and 10-bit (.mov and .mxf)
• DNxHR (.mov and .mxf)
• MPEG2 program stream and transport stream (4:2:0 and 4:2:2)
• DV (.avi, .mov, .mxf, rawDV)
• DVCPRO (.avi and .mov)
• DVCPRO HD (.mov)
