OWC Gemini Thunderbolt 3 Dock & Dual-Drive RAID External Storage

Comprehensive Tool for Digital Workflows

The OWC Gemini features dual drive bays and seven connectivity ports, including an SD 4.0/UHS-II media slot, making it an all-in-one tool to organize your digital life. It provides ample space to back up footage, create and manage archives, or render and process effects. Connect your favorite peripherals via USB ports and import footage from cameras or drones using the front-facing card reader.

Key Features

• Efficient data storage up to 562 MB/s
• Fast connectivity with two Thunderbolt 3 ports (backward compatible with Thunderbolt 2/Thunderbolt)
• Hardware RAID controller supporting RAID 0, 1, Span, or JBOD/independent modes
• Easy upload from camera via front SD 4.0 (UHS-II) card reader
• Hub center with two USB 3.2 (10 Gb/s) Type-A ports
• 2.5 Gb/s Ethernet port for NAS connection
• HDMI 2.1 output supporting up to 8K monitors
• Custom configurations for two 2.5" or 3.5" SATA or U.2 drives
• Innergize-enabled full health, performance, and field update management via OWC Atlas SD cards with Gemini SD reader
• 3-year OWC limited warranty

Hardware RAID: Speed, Reliability, Flexibility

The OWC Gemini utilizes hardware RAID to fully unleash the potential of two 3.5" 7200 RPM hard drives or 2.5" SATA SSDs. Preconfigured in high-speed RAID 0 mode for maximum throughput, it delivers real disk speeds up to 562 MB/s, ideal for audio editors, musicians, individual content creators, photographers, small studios, and filmmakers working with up to 4K resolution and compressed codecs. For A/V professionals seeking SSDs with sustained full-speed performance, OWC Mercury Extreme SSDs offer proven reliability. With consistent RAID 0 speeds up to 956 MB/s, you can easily handle 8K single and 4K multi-sequence, slow-motion video, 10-bit video, and ultra-high-resolution RAW images. For added data security, configure Mercury Gemini in RAID 1 mode. Need more disk flexibility? Set Span to combine both drives into one large volume or use drives as independent volumes.

Stay Connected with Your Team and Media

Equipped with a 2.5 Gb/s Ethernet port, the OWC Gemini enables file transfers and work up to 2.5 times faster over wired networks, enhancing productivity in IP-based workflows. Perfect for shared workspaces and workflows, fast file transfers mean less setup time and more work time. When ready to share, use RAID options for playback and fast connections to publish work for team and client reviews. It also facilitates file transfers to NAS for secure archiving.

Gain an 8K Perspective

With a dedicated next-generation HDMI port, Gemini allows you to add a fresh, clear 8K display perspective to your workflow. Whether in a home office or mobile studio, your work is visible in full detail just one connection away. This frees up your laptop ports for quick connect/disconnect and maintains mobility.

Reclaim Your Desktop

Multiple media drives, controllers, A/V outputs, and device cables can clutter your workspace. OWC Gemini combats clutter with a single-cable connection providing storage, Ethernet sharing, charging power, and 8K monitor support, neatly consolidating all peripheral cables. Reclaim your workspace and reduce stress.

RAID Performance as Mobile as Your Life

With a built-in hardware RAID controller, you get speed and security independent of your operating system. Easily connect OWC Gemini to Mac and PC using OWC MacDrive software (sold separately) for cross-platform workflows.

One-Click Safe Eject

Safely eject multiple drives with one click. Developed by OWC hardware and software engineers, OWC Dock Ejector ensures all data is written before disconnection, saving time and protecting against data loss. Protect your hard-earned work.

Included OWC Thunderbolt Cable

The OWC Gemini includes a certified 0.7 m OWC Thunderbolt cable. For other cable lengths, OWC Thunderbolt (USB-C) cables are an excellent choice.

Stabilize Thunderbolt and USB-C Cables

In active work environments, equipment is subject to bumps, knocks, or even accidental pet tail tugs. OWC ClingOn custom cable stabilizers (sold separately) screw into the OWC dock or drive enclosure to reduce or eliminate Thunderbolt and USB-C cable strain, ensuring secure connections even in demanding environments.

Optimize Workflow with Highest Performance and Reliability

OWC Innergize is the first step in the OWC Capture to Completion ecosystem, designed to provide professional photographers, videographers, and content creators with the highest workflow performance and reliability. This specially developed OWC app offers complete health, performance, and field update management for OWC Atlas memory cards with OWC Atlas readers and compatible products.

Health

Flash memory wears over time and usage cycles. Innergize monitors and reports the remaining lifespan percentage, allowing you to work confidently knowing your OWC flash memory product will deliver reliable performance.

Sanitization

Recording, deleting, and formatting degrade memory cards. Innergize cleans and restores OWC memory card flash performance for optimal results every use.

Updates

New cameras or firmware updates may cause incompatibility with memory cards and drives. Innergize enables OWC memory card users to quickly update firmware on-site, ensuring full compatibility, enhanced performance, and bug fixes for optimal reliability.

Note: Thunderbolt 2/Thunderbolt compatibility requires a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 (mDP) adapter and Thunderbolt 2 cable. This setup provides data transfer at Thunderbolt 2 speeds (up to 20 Gb/s) but does not support laptop charging.

Package Includes

• OWC Gemini Thunderbolt dock and external storage solution
• 0.7 m (29") Thunderbolt (USB-C) cable
• External power supply and power cable
• OWC Gemini quick start guide
• OWC Gemini user manual
• OWC Dock Ejector for Mac and Windows (software download)
• OWC Dock Ejector user manual
• 3-year OWC limited warranty
