JJC LED AP Mini LED Light - Compact fill light for Insta360 cameras, 150 lm,

JJC LED AP Mini LED Light

The JJC LED AP Mini LED Light is a compact fill light designed specifically for Insta360 cameras, featuring a magnetic quick release mount, flicker-free output, and IPX5 water resistance.

Highlights

• Designed specifically for Insta360 X4 Air / X5 / ACE PRO / ACE PRO2 / ACE
• Magnetic quick release design for instant attachment
• 20 LED chips with CRI ≥95 for accurate colour reproduction
• Flicker-free output for stable video recording
• Three brightness levels (50 / 75 / 100) plus SOS mode
• IPX5 water resistance for outdoor use

Light Performance

The LED AP features 20 LED chips (2835/0.2 W) with a 120° beam angle for soft, even illumination. The colour temperature is 6500 K ±200 K, and maximum illuminance reaches 195 lux at 0.5 m. Maximum luminous flux is 150 lm and maximum power consumption is 1.6 W. With a CRI of ≥95, colours are rendered naturally and accurately.

Battery and Charging

The built-in lithium battery (3.7 V / 500 mAh) charges fully in approximately 1 hour via the USB C port (5 V / 1 A). At maximum brightness (100), runtime exceeds 1 hour; at 50 brightness this extends to over 3 hours. The power off memory function automatically restores the last used brightness level when switched on.

Controls

The light is operated with a single button long press to power on or off, short press to cycle through brightness levels. In addition to the three brightness levels, an SOS emergency mode is also available.

Compatibility and Mounting

The LED AP is designed specifically for the Insta360 X4 Air, X5, ACE PRO, ACE PRO2 and ACE. The magnetic quick release slides into the camera's quick release slot until an audible click confirms secure attachment.

Specifications

• Model: LED AP
• LED chips: 20 2835 / 0.2 W
• Maximum luminous flux: 150 lm
• Maximum illuminance: 195 lux at 0.5 m
• Maximum power: 1.6 W
• Colour temperature: 6500 K ±200 K
• CRI: ≥95
• Beam angle: 120°
• Brightness levels: 50 / 75 / 100
• Flicker-free: Yes
• SOS mode: Yes
• Battery: 3.7 V / 500 mAh lithium
• Charging method: USB C
• Input: 5 V / 1 A
• Charging time: ~1 hour
• Runtime: ~1 hour (100) / ~3 hours (50)
• Power off memory: Yes
• Water resistance: IPX5
• Material: ABS + PC
• Colour: Black
• Dimensions: 44.2 x 39.6 x 24.1 mm
• Weight: ~40 g
• Operating temperature: -20°C to 50°C
• Warranty: 2 years
