Newell Vividha Max 216 RGBWW LED Panel 40W with Adapter

Compact RGBWW LED Panel for Creative Lighting

The Newell Vividha Max is a compact and slim LED panel designed for filmmakers and photographers seeking precise control over lighting parameters including color, color temperature, and brightness. It features a built-in tripod mount and adjustable tilt angle, enhancing flexibility on set. Included accessories such as metal gates and a diffuser improve light shaping and softening capabilities. An ergonomic control knob and a clear TFT display enable quick and intuitive adjustments. Additionally, the panel offers 9 thematic lighting programs to simulate various cinematic effects.

Main Features

• Brightness adjustment from 0 to 100% via ergonomic knob
• Color control in HSI color space with 216 RGBWW LEDs
• Color temperature adjustable from 2500 K to 8500 K
• High color rendering index (CRI > 95) for accurate color reproduction
• 9 special effect programs including Paparazzi, Fireworks, Faulty Bulb, Party, Lightning, TV, Pulsing, Cop Car, and Fire
• Adjustable tilt angle for directional lighting
• Tripod mounting screw for stable setup
• Includes diffuser and metal gates with independently operating wings for precise light control
• Powered by included 15V DC, 3A power adapter or two NP-F lithium-ion batteries (sold separately)
• Clear TFT screen for easy parameter monitoring and control

Advanced Lighting Control

The panel’s 216 RGBWW LEDs allow for extensive color experimentation within the HSI color space, offering 36 hue options and 10 brightness levels. The CCT mode enables smooth adjustment of color temperature across a wide range, supporting creative lighting setups for both photography and videography.

Special Effects for Cinematic Atmosphere

With 9 built-in thematic programs, the Newell Vividha Max can simulate various lighting effects such as flashing paparazzi lights, fireworks, flickering faulty bulbs, party lighting, lightning storms, TV screen flicker, pulsing light, police car sirens, and fire glow. Each effect is customizable in terms of color temperature and flash frequency, allowing for tailored cinematic looks.

Power Options and Portability

The LED panel supports dual power options: via the included AC adapter or through two NP-F rechargeable batteries, enabling use in studios or on location without access to mains power. This versatility ensures freedom of movement and flexibility during shoots.

Light Shaping Accessories

Included metal gates with four independently adjustable wings allow precise control over light direction and spill, while the lightweight diffuser softens light output to reduce harsh shadows and create natural illumination. The diffuser can be quickly attached or removed within seconds.

Transport and Storage

A practical zippered carrying case is provided for safe storage and convenient transport of the lamp, diffuser, gates, and power supply. An inner elastic pocket offers additional space for accessories.

Technical Specifications

• Model: Newell RGB Vividha Max
• LEDs: 216 x 0.5 W RGBWW LEDs
• Maximum power consumption: 40 W
• Maximum light intensity: 1200 lux at 1 meter
• Color temperature range: 2500 K to 8500 K (adjustable)
• Color rendering index (CRI): > 95
• Display: TFT screen
• Brightness control: 0–100% in 10 steps
• Power supply: DC 15V, 3A adapter (included) or NP-F lithium-ion batteries (sold separately)
• Connection: DC plug
• Operating temperature: 0 to 35 °C
• Storage temperature: -10 to 50 °C
• Relative humidity: 20% to 90%
• Dimensions: 275 x 68 x 258.5 mm
• Weight: 1202 g

Kit Contents

• Newell RGB Vividha Max LED lamp
• Diffuser
• Metal gates
• Power supply adapter
• Power cable
• Carrying case
