OWC Jupiter Kore 2U Rack NAS Expansion 128TB
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Network Attached Storage (NAS) |
| Capacity | 128TB |
| Connector | Mini-SAS HD |
| Color | Black |
| Media type | Network Attached Storage (NAS) |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
OWC Jupiter Kore Enterprise-Class Storage
Enhance your data storage capabilities with the OWC Jupiter Kore storage system, designed for high performance, large capacity, reliability, and cost efficiency. It features two Mini-SAS HD interface ports, each providing 48Gb/s bandwidth, enabling rapid data transfer suitable for demanding professional applications.
Storage Expansion Features
- Available in rack-mounted 2U and 3U form factors
- High-speed 12Gb Mini-SAS HD interface connectivity
- Supports configurations from 16TB to 64TB SSD or 32TB to 320TB HDD
- Expandable up to 2.5PB using a single Callisto service and up to seven Kore units
- Compatible with Mac, PC, and Linux operating systems
Utilize both Mini-SAS HD ports simultaneously to achieve combined throughput of up to 96Gb/s, or use the second port to increase JBOD storage capacity. The Kore system also supports expansion of existing RAID arrays such as the OWC Jupiter Callisto.
Capacity and Expansion
The Kore system offers up to 160TB of raw storage in a 2U rack with 8 drives, and up to 320TB in a 3U rack with 16 drives. Multiple Kore units can be interconnected via Mini-SAS to scale storage capacity up to 2.5PB on 3U systems.
RAID and Performance
Designed for high-performance RAID storage, the Kore system connects seamlessly to Mini-SAS RAID controller cards and adapters. It also extends storage for networked storage servers like the OWC Jupiter Callisto.
Mini-SAS HD Interface Speed
The Mini-SAS HD interface delivers single-cable speeds up to 48Gb/s, with dual cables enabling up to 96Gb/s total bandwidth. This high throughput supports accelerated workflows, increased video ingestion rates, simultaneous video editing, and efficient data transfer.
Rack Options and Flexibility
Choose between 8-drive 2U racks or 16-drive 3U racks to suit your installation requirements and available rack space.
Hot-Swappable Components
Drives and fans are hot-swappable, allowing maintenance or upgrades without interrupting system operation.
Redundant Power Supply
Equipped with robust, redundant power supplies featuring hot-swap capability and load balancing to ensure continuous 24/7 operation.
Specifications - 8 Drive (2U)
- Rack space: 2U
- Internal raw capacity: 16-32TB SSD or 32-160TB HDD
- Supports Mini-SAS storage expansion
- Dimensions (W×H×D): 48.0 cm × 9.4 cm × 73.7 cm
- Weight without drives: 13.56 kg
- Interfaces: 2 Mini-SAS HD (12Gb/s) SFF-8644 ports
- Channels: 8 SAS-3 compliant 12Gb/s channels, total bandwidth 96Gb/s (48Gb/s per port)
- Power supply: 380W high-efficiency 1+1 redundant, 90–264 VAC auto-switching
- Operating environment: 0°C to 40°C, 20% to 95% non-condensing humidity
- Storage environment: -20°C to 80°C, 10% to 95% non-condensing humidity
- Warranty: 3 years limited, expandable up to 5 years
Specifications - 16 Drive (3U)
- Rack space: 3U
- Internal raw capacity: 32-64TB SSD or 64-320TB HDD
- Supports Mini-SAS storage expansion up to 2.5PB
- Dimensions (W×H×D): 48.0 cm × 13.2 cm × 73.7 cm
- Weight without drives: 18.37 kg
- Interfaces: 2 Mini-SAS HD (12Gb/s) SFF-8644 ports
- Channels: 8 SAS-3 compliant 12Gb/s channels, total bandwidth 96Gb/s (48Gb/s per port)
- Power supply: 650W 2+1 redundant active PFC, 90–264 VAC auto-switching
- Operating environment: 0°C to 40°C, 20% to 95% non-condensing humidity
- Storage environment: -20°C to 70°C, 10% to 95% non-condensing humidity
- Warranty: 3 years limited, expandable up to 5 years
