Swit S-3812S Dual-Channel V-Mount Battery Charger
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Charger |
| Battery type | Charger |
| Battery compatible | Sony NP-F980 |
| Battery compatible | Canon LP-E6 |
| Barošana | no tīkla |
| Connections | D-tap and DC male |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
Dual-Channel Fast Charger S-3812S
- 2-channel V-mount fast charger capable of simultaneous charging
- Automatically identifies battery type and adjusts charging method accordingly
- 6A fast charging current for SWIT specific batteries
- 3A charging current for standard batteries
- Supports AC to 4-pin XLR output for powering external equipment
- Supports battery to 4-pin XLR output for DC power supply
- LCD display provides detailed charging and adapting information
Maximum Charging Current of 6A
The S-3812S charger can simultaneously charge two V-mount batteries at a maximum current of 6A for SWIT specific battery models, enabling significantly faster charging compared to standard chargers. Supported battery models for 6A fast charging include:
- PB-H290S
- PB-S220S
- PB-R160S
- PB-R290S
- S-8340S
- S-8360S
- D-8161S
- S-8180S
- S-8113S
- S-8183S
For other battery types, the charging current is limited to 3A.
Charging Time Comparison
Charging durations vary by battery model, with the S-3812S significantly reducing charge times compared to normal chargers:
- S-8340S: 2 hours 35 minutes (normal 6 hours 20 minutes)
- S-8360S: 3 hours 50 minutes (normal 9 hours 30 minutes)
- D-8161S: 2 hours 55 minutes (normal 7 hours 40 minutes)
- D-8113S: 2 hours 35 minutes (normal 6 hours 20 minutes)
- S-8180S: 3 hours 30 minutes (normal 8 hours 30 minutes)
- S-8183S: 3 hours 50 minutes (normal 9 hours 30 minutes)
AC-DC Adapting Output
The charger supports a single-channel AC-DC adapting output via a 4-pin XLR port. Using the S-7102 cable (4-pin XLR female to male), it can supply 16.8V DC power to external equipment with a maximum load of 200W (12A). When the adapting load is below 100W, the charger can still charge two batteries sequentially.
Battery-DC Adapting Output
Mounted batteries on the S-3812S can provide DC power output through the 4-pin XLR port. The S-7102 cable enables 16.8V DC power delivery to other devices with a maximum load of 200W (12A).
LCD Charging Information Display
The integrated LCD screen displays real-time charging and adapting data, including:
- Battery charging and discharging status
- Real-time capacity and percentage
- Real-time voltage and current
- Remaining time to full charge
- Remaining time to full discharge
- Battery cycle count
- Adapting output current and power
Note: Detailed battery information display is available only with SWIT digital Li-ion batteries (models S-8320S, S-8340S, S-8360S, D-8161S/R). For non-digital batteries, the display shows only real-time voltage and current.
3-Color LED Indicators
The charger features 3-color LED indicators for each channel to indicate status:
- Red light slow flash: Battery is charging
- Red light fast flash: Battery nearing full charge
- Green light steady: Battery fully charged
- Green light flashing: Battery in adapting output mode
- Orange light flashing: Battery or charger abnormal alert
