Swit SC-302A 2ch Charger Gold-mount

Overview

The SWIT SC-302A is a 2-channel Gold Mount (Anton Bauer mount) sequential charger designed to charge two batteries one at a time. Featuring LED charging indicators, optimized Li-ion charging curves, and multiple safety protections, it delivers safe and reliable battery charging for professional broadcast and cinema applications.

Charging Process

The SC-302A follows a two-stage Li-ion charging process for maximum efficiency and protection. The first stage applies constant current at the maximum charge rate. Once the battery reaches the target voltage, the charger switches to a constant voltage stage, supplying only the necessary current to maintain voltage and prevent overcharging.

LED Charging Indicators

Each channel features LED indicators on the front panel that display real-time charging status through different colors, allowing users to easily monitor battery progress.

Advanced Safety Protection

The SC-302A is designed with multiple safety protections. It can identify different battery chemistries and automatically apply the appropriate charging program to prevent:

• Overcurrent
• Overcharging
• Overheating
• Voltage irregularities

Key Features

• Dual Gold Mount (Anton Bauer mount) charging plates
• Sequential charging (charges batteries one at a time)
• DC 14.2V / 1.9A charging output
• LED charging status indicators
• Two-stage Li-ion optimal load curve
• Multiple safety protection systems
• Compact and portable design

Specifications

• Input: AC 100-240V, 50/60Hz
• Output: DC 14.2V, 1.9A
• Charging Mode: Sequential (2 channels)
• Compatible Batteries: Anton Bauer Mount (Gold Mount)
• Dimensions: 228 x 140 x 86 mm
• Weight: 0.85 kg
