DeckLink IP/SDI HD Blackmagic Design Capture Card
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Blackmagic Design |
| Connector | USB-C |
| Connector | USB 3.1 |
| Connector | SDI |
| Connector | HDMI |
| Connector | Thunderbolt |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
Blackmagic Design DeckLink IP
Blackmagic Design DeckLink IP is a family of PCIe capture and playback cards designed for 10-bit uncompressed, broadcast quality video integration into SMPTE 2110 IP-based broadcast systems. These cards support multiple simultaneous video channels for capture and playback.
Models
- DeckLink IP HD: Provides 3 channels of capture and playback via a single RJ45 Ethernet connection to 2110 IP broadcast systems.
- DeckLink IP HD Optical: Offers 3 channels of capture and playback through an SFP-based optical fiber Ethernet connection to 2110 IP broadcast systems.
- DeckLink IP/SDI HD: Enables connectivity to both 3G-SDI and 2110 IP systems, featuring 2 capture and playback channels to 2110 IP via RJ45 Ethernet, 3G-SDI inputs/outputs, and reference output.
Video Standards
All models support HD video formats including 720p, 1080i, and 1080p up to 60 frames per second. Availability began in June 2023.
Features
DeckLink IP cards provide seamless capture and playback directly into 2110 IP broadcast infrastructures while maintaining full compatibility with existing DeckLink software features. This enables integration into server racks for broadcast graphics generation, virtual sets, and GPU-accelerated AI image processing within 2110 IP environments. Additionally, these cards support DaVinci Resolve for editing workflows based on 2110 IP broadcast systems.
Connection Interface
Equipped with a high-speed PCIe interface, DeckLink IP cards are compatible with modern Mac Pro, Windows, and Linux workstations.
Supported Codecs
- AVCIntra
- AVCHD
- Canon XF MPEG2
- Digital SLR
- DVNTSC
- DVPAL
- DVCPRO50
- DVCPROHD
- DPX
- HDV
- HEVC
- XDCAM EX
- XDCAM HD
- XDCAM HD422
- DNxHR & DNxHD
- Apple ProRes 4444
- Apple ProRes 422 HQ
- Apple ProRes 422
- Apple ProRes LT
- Apple ProRes 422 Proxy
- Uncompressed 8-bit 4:2:2
- Uncompressed 10-bit 4:2:2
- Uncompressed 10-bit 4:4:4
IP Video Compliance
The DeckLink IP cards comply with key industry standards for IP video transport and synchronization, including:
- SMPTE 2110-20 (Uncompressed Video)
- SMPTE 2110-21 (Traffic Shaping)
- SMPTE 2110-30 (PCM Audio)
- SMPTE 2110-40 (Ancillary Data)
- IEEE 1588-2008 (PTP v2) / ST 2059-1 / ST 2059-2 for timing and synchronization
- NMOS IS-04 (Discovery and Registration)
- NMOS IS-05 (Device Connection Management)
- NMOS BCP-002-01 (Best Current Practice for NMOS)
- NMOS BCP-004-01 (Best Current Practice for NMOS)
