Sennheiser AB 4-GW Antenna amplifier 558-626 MHz
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Antenna amplifiers |
| Connection type | Radio |
| Accessories for microphones | Antennas |
| Connector | other |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
The Sennheiser AB 4-GW is a compact inline antenna booster for evolution wireless G4 systems, providing +10 dB gain to offset signal loss from long cable runs across an 88 MHz tuning bandwidth (558-626 MHz). Featuring BNC connectors, filtered design for RF interference rejection, and full compatibility with G3 systems, it measures 4.9 x 1.0 x 3.2 inches and weighs 0.4 lb, ideal for reliable wireless mic setups in live sound or broadcast.
The Sennheiser AB 4-GW Antenna Booster represents an evolution in RF signal amplification for professional wireless audio, specifically tailored to the expanded switching bandwidth of Sennheiser's ew G4 series (ew 300 G4, ew 500 G4), delivering a consistent +10 dB gain to counteract attenuation from extended coaxial cable runs (up to 100 m RG-58 without degradation). Operating in the GW frequency range (558-626 MHz, 88 MHz bandwidth), its inline module incorporates active bandpass filtering (3 dB cutoff slopes) to suppress out-of-band interference and harmonics, ensuring clean signal distribution in multi-channel environments like theaters, houses of worship, or ENG productions. The rugged, weather-resistant aluminum housing (IP54-rated) houses BNC female input/output connectors (50 Ω impedance, VSWR <1.51), supporting daisy-chaining up to 4 units per antenna line while maintaining phantom power passthrough (9-18 V DC, <50 mA draw). Backward-compatible with legacy ew G3 systems, it enhances RF reliability without recalibration, and its low noise floor (NF <2.5 dB) preserves dynamic range for vocal/instrument mics. At just 4.9 x 1.0 x 3.2 inches (12.4 x 2.6 x 8.2 cm) and 0.4 lb (0.2 kg), the AB 4-GW mounts discreetly via VESA brackets or adhesive, powering via external 12 V adapter (not included) for seamless integration into A/B antenna combiners or remote head systems.
Key Features
- +10 dB active gain with bandpass filtering for extended cable runs (up to 100 m)
- 88 MHz tuning bandwidth (GW 558-626 MHz) optimized for ew G4 systems
- BNC inline connectors Low-loss (0.2 dB/ft at 600 MHz), supports daisy-chaining
- RF interference rejection Suppresses out-of-band noise (>40 dB attenuation)
- Full G3/G4 compatibility Phantom power passthrough, no recalibration needed
- Compact aluminum housing IP54-rated, lightweight for portable or fixed installs
- 1 Compact inline antenna booster
- Frequency Range GW (558-626 MHz, 88 MHz bandwidth)
- Gain +10 dB
- Connectors BNC Female (input/output, 50 Ω)
- Power 9-18 V DC phantom (via BNC), <50 mA
- Noise Figure <2.5 dB
- VSWR <1.51
- Dimensions 4.9 x 1.0 x 3.2" / 12.4 x 2.6 x 8.2 cm
- Weight 0.4 lb / 0.2 kg
- Housing Aluminum (IP54 dust/moisture resistant)
- Operating Temperature -10°C to +50°C
