Blackmagic Cable for UltraStudio and DeckLink Studio

Purpose and Compatibility

This breakout cable is designed specifically for use with Blackmagic Design's professional video capture and playback hardware, including the DeckLink Studio 4K and UltraStudio 4K Extreme series (UltraStudio 4K Extreme and UltraStudio 4K Extreme 3). It provides the necessary external connector breakout to expand the rear connectivity of these devices.

Supported Signal Types

• Digital Video: Supports SD, HD, and Ultra HD SDI signals on compatible DeckLink and UltraStudio models.
• Analog Video: Supports component YUV, composite, and S-Video signals on DeckLink Studio 4K.
• Audio and Control: Supports balanced analog audio, AES/EBU digital audio, and RS-422 deck control on DeckLink Studio 4K. RS-422 deck control is also supported on UltraStudio models using this cable kit.

Functionality

The cable enables capture, playback, monitoring, and deck control functions in professional video workflows by providing specialized breakout connections not available through standard consumer AV cabling.

Additional Information

While exact cable length, connector pinout, and detailed package contents are not specified, this cable is essential for connecting and utilizing the full range of analog and digital inputs and outputs on supported Blackmagic hardware.
