Infinitek L-3C2VS BLU BNC 0.3m

Canare L-3C2VS BLU BNC (M-male) / BNC (M-male) 0.3m

Canare L-3C2VS is a lightweight and flexible 5.5 mm HD/SD-SDI coaxial cable with a braided center conductor and a tightly woven shielded outer conductor. It remains flexible even at low temperatures. Both ends have crimp-on BNC (M) connectors type BCP-A3.

Application

• HD/SD-SDI video
• PAL and NTSC analog video
• Satellite applications
• TELCO
• Test equipment
• Rack cabling
• Patch cables for video

Cable Specifications

• Sheath diameter (overall diameter) in mm 5.5
• Cable weight in kg/100 m 4.5
• Medium conductor - number and diameter of cores in mm 7/0.18
• Total diameter of the middle conductor in mm 0.54
• Foam dielectric - diameter in mm 3.1
• Resistance of the middle conductor in ohms/100 m 10.5
• Resistance of the outer conductor in Ohm/100m 1.9
• Static capacitance in pF/m 67
• Attenuation in dB/100m 4.5
• Impedance in ohms 75

Connector specifications

• Tensile strength in kg U0026gt;24.9
• Insulation resistance at 500 V DC in Ohms 24.5 mm U0026gt;1000M
• Rated voltage for 1 min 1500 V AC (effective value)
• Center contact resistance 1.5 mm U0026lt;6m ohms
• External contact resistance contact strength U0026lt;3m ohm
• Impedance in ohms 75
• Connector body - material/surface brass/nickel
• Center contact - material/surface brass/gold
• Outer contact - material Beryllium copper
• Dielectric - Material PTFE polytetrafluoroethylene
• Crimp sleeve - material/surface copper/tin
