FNIRSI 1013D 7 portable tablet oscilloscope

FNIRSI 1013D 7 portable tablet oscilloscope

The FNIRSI 1013D portable oscilloscope features a 7-inch touch screen, 2 measurement channels, 100 MHz bandwidth, and 1 GSa/s sampling rate for precise signal analysis in various applications. It includes an 800x480 TFT screen, automatic one-button signal adjustment, and waveform recording, making it ideal for service, workshops, and electronic device design. The built-in 6,000 mAh lithium battery provides approximately 4 hours of operation.

Clear touchscreen

The 7-inch TFT LCD screen with 800x480 resolution offers high brightness and accurate waveform reproduction. Touch operation allows for quick adjustments, enhancing efficiency. The cursor measurement function enables precise readings of signal parameters without unit conversion, beneficial for distorted signals.

Two measurement channels

Equipped with two measurement channels, the device allows simultaneous analysis of two signals, facilitating comparisons in amplifier circuits and PWM signal analysis. It supports Lissajous pattern analysis in XY mode for frequency and phase shift determination.

Automatic signal adjustment

The one-button automatic adjustment function quickly calibrates signal parameters, enhancing efficiency. The built-in fuzzy logic algorithm ensures accurate signal placement on the screen for easier analysis.

Protection against damage

Built-in surge protection modules up to 400 V safeguard the device during high-voltage measurements, allowing safe testing of power circuits.

Data storage and export

With 1 GB of internal memory, the FNIRSI 1013D can store up to 1,000 images and waveforms, enabling quick saving and USB export for further analysis. The waveform manager function allows easy viewing and management of stored data.

Advanced triggering functions

The oscilloscope features multiple trigger modes (Auto, Single, Normal) for versatile testing of various signals. Users can set trigger edges and channels for precise signal capture.

Included

• FNIRSI 1013D portable touchscreen oscilloscope
• Probe (100 MHz) x2
• USB charger
• User manual
