Swit PL-E90LH LED panel
- Lux/1m 2000
- Light color quality (CRI) cri 99 / tlci 99
- Compatible gold mount
- Compatible v-mount
- Compatible dmx/app control
- Color temperature 2700 k – 6500 k
- Power Watt 90
- Light dimming 0-100% dimmable (pwm)
- LED light type panelis
- Power Supply v-mount
- Power Supply ac/dc adapter included
- Power Supply gold mount
- Weight, gr 1500
- Height, m 0.075
- Number of LEDs 480
- Number of LEDs 480 smd
- Type of Product led panel light
- Lux/1m 2000
- Light color quality (CRI) cri 99 / tlci 99
- Compatible gold mount
- Compatible v-mount
- Compatible dmx/app control
- Color temperature 2700 k – 6500 k
- Power Watt 90
- Light dimming 0-100% dimmable (pwm)
- LED light type panelis
- Power Supply v-mount
- Power Supply ac/dc adapter included
- Power Supply gold mount
- Weight, gr 1500
- Height, m 0.075
- Number of LEDs 480
- Number of LEDs 480 smd
- Type of Product led panel light
AI ASSISTANT CHAT
Or ask about:
| Type of Product | LED Panel Light |
| Compatible | Gold Mount |
| Compatible | DMX/App control |
| Compatible | V-Mount |
| Lux/1m | 2000 |
| Color temperature | 2700 K – 6500 K |
| Light dimming | 0-100% dimmable (PWM) |
| LED light type | panelis |
| Power Watt | 90 |
| Power Supply | Gold Mount |
| Power Supply | AC/DC adapter included |
| Power Supply | V-Mount |
| Number of LEDs | 480 SMD |
| Number of LEDs | 480 |
| Light color quality (CRI) | CRI 99 / TLCI 99 |
| Weight, gr | 1500 |
| Height, m | 0.075 |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
SWIT PL-E90LH LED Panel
The SWIT PL-E90LH is a 90W ultra-slim bi-color LED panel with an 81 aspect ratio, designed for ceiling and studio installations. Featuring high color accuracy, silent operation, DMX control, and V-Mount/Gold Mount battery support, it is ideal for professional broadcast and video environments.
The PL-E90LH is engineered for modern studios, especially low-ceiling installations. With its ultra-slim 2.1 cm design and included mounting bracket, it minimizes height occupancy while maximizing usable lighting angles. The unique 81 aspect ratio and advanced 90 light guide technology deliver smooth, even illumination across wide areas, making it ideal for key, fill, or background lighting.
Equipped with 480 high-efficiency SMD LEDs, the PL-E90LH produces up to 2000 lux at 1 meter and supports flicker-free dimming from 0-100. The bi-color output is continuously adjustable from 2700K to 6500K, ensuring excellent flexibility for mixed lighting conditions. Exceptional color accuracy with CRI Ra 99 and TLCI 99 ensures true-to-life color reproduction for broadcast and cinematic work.
Designed for professional control, the PL-E90LH supports DMX512 and includes a USB output for connecting a wireless DMX receiver. An onboard LCD displays color temperature, dimmer level, DMX address, and battery status. Power options include wide-range DC input (11-36V) as well as V-Mount or Gold Mount battery compatibility. Integrated barndoors allow precise light shaping and spill control.
Key Features
- 90W bi-color LED panel with ultra-slim 2.1 cm design
- 81 aspect ratio ideal for ceiling and studio mounting
- 480 high-output SMD LEDs
- Unique 90 light guide technology for even illumination
- Output 2000 lux at 1 m
- Flicker-free 0-100 dimming
- Color temperature adjustable from 2700K to 6500K
- Exceptional color accuracy CRI Ra 99, TLCI 99
- DMX512 control support
- USB output for wireless DMX receiver
- LCD display for color, dimmer, DMX, and battery info
- Wide DC input voltage 11-36V
- V-Mount and Gold Mount battery compatible
- Integrated barndoors for light control
- Includes bracket for ceiling mounting structures
Specifications
- Model: SWIT PL-E90LH
- Power Consumption: 90 W
- LED Type: 480 SMD LEDs
- Illuminance: 2000 lux at 1 m
- Aspect Ratio: 81
- Color Temperature: 2700K - 6500K (continuous)
- Dimming: 0-100, flicker-free
- Color Accuracy: CRI Ra 99, TLCI 99
- Control: DMX512
- Power Input: DC 11-36 V
- Battery Support: V-Mount / Gold Mount
- Panel Thickness: Approx. 2.1 cm
