TelyCam Drive+ N 12X - white
- Color white
- CMOS Sensor 1080p (1920 x 1080) fhd
- Type of Product ptz camera
- Video Resolution hd 1080
- Optical Zoom 12x
- Video Interface hdmi
- Video Interface 3g-sdi
- Video Interface usb 3.0
- Video Interface rj-45
- Features ndi technology
- Features on-board record
- Features auto tracking
- Features poe
- Features supports multiple control protocols
- PoE Technology poe+
- IP Video ndi hx
- IP Video srt
- IP Video rtmp
- IP Video rtsp
- Control Protocol visca
- Control Protocol rs-232
- Control Protocol rs-422
- Control Protocol rs-485
- Control Interface rs-232
- Control Interface rs-422
- Control Interface rs-485
- Color white
- CMOS Sensor 1080p (1920 x 1080) fhd
- Type of Product ptz camera
- Video Resolution hd 1080
- Optical Zoom 12x
- Video Interface hdmi
- Video Interface 3g-sdi
- Video Interface usb 3.0
- Video Interface rj-45
- Features ndi technology
- Features on-board record
- Features auto tracking
- Features poe
- Features supports multiple control protocols
- PoE Technology poe+
- IP Video ndi hx
- IP Video srt
- IP Video rtmp
- IP Video rtsp
- Control Protocol visca
- Control Protocol rs-232
- Control Protocol rs-422
- Control Protocol rs-485
- Control Interface rs-232
- Control Interface rs-422
- Control Interface rs-485
AI ASSISTANT CHAT
Or ask about:
| Type of Product | PTZ Camera |
| CMOS Sensor | 1080p (1920 x 1080) FHD |
| Color | White |
| Video Resolution | HD 1080 |
| Optical Zoom | 12x |
| Video Interface | 3G-SDI |
| Video Interface | RJ-45 |
| Video Interface | HDMI |
| Video Interface | USB 3.0 |
| Features | Supports Multiple Control Protocols |
| Features | On-Board Record |
| Features | PoE |
| Features | NDI Technology |
| Features | Auto Tracking |
| PoE Technology | PoE+ |
| IP Video | NDI HX |
| IP Video | RTMP |
| IP Video | SRT |
| IP Video | RTSP |
| Control Protocol | RS-485 |
| Control Protocol | VISCA |
| Control Protocol | RS-422 |
| Control Protocol | RS-232 |
| Control Interface | RS-422 |
| Control Interface | RS-232 |
| Control Interface | RS-485 |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
The Telycam Drive+ N 12X PTZ Camera
The Telycam Drive+ N 12X PTZ Camera is a Full HD professional PTZ camera featuring a 1/2.8" CMOS sensor, 12 optical zoom, and flexible connectivity including NDIHX, HDMI, 3G-SDI, and USB 3.0, designed for streaming, conferencing, and multi-platform video production.
Versatile for Professional Use
The Telycam Drive+ N 12X is built for professional video production environments such as studios, classrooms, houses of worship, corporate meeting spaces, and live streaming setups. It delivers Full HD resolution up to 1080p60, ensuring smooth and detailed video output suitable for both live and recorded applications.
Image Quality and Zoom
Equipped with a 1/2.8-inch 2.4MP CMOS sensor, the camera provides reliable image quality with good low-light performance. Its 12 optical zoom lens (f3.92-47.32 mm) allows users to capture both wide-angle scenes and detailed close-ups without sacrificing clarity. With a horizontal field of view ranging from 72° to 6.3°, it adapts well to both small and medium-sized spaces.
Flexible Connectivity
The Drive+ N supports multiple simultaneous output interfaces, including NDIHX over IP, HDMI, 3G-SDI, and USB 3.0. This makes it highly flexible for integration into different workflows, whether using IP-based streaming systems, traditional broadcast setups, or USB webcam applications. It also supports popular streaming protocols such as SRT, RTMP, and RTSP for direct internet streaming.
Network and Control
Network connectivity is handled via a Gigabit Ethernet port with PoE+ support, allowing the camera to be powered and controlled through a single cable. In addition, RS232, RS485, and USB interfaces provide compatibility with VISCA and other control protocols, enabling precise remote camera operation and integration into professional control systems.
Pan-Tilt Mechanics
The camera features smooth pan-tilt mechanics with a wide range of motion and fast, precise movement. It supports up to 128 preset positions, making it easy to switch between predefined shots during production. Image tuning options such as white balance, exposure, gamma, WDR, and noise reduction allow fine control over video output.
Compact Design
Compact and easy to mount (wall, ceiling, or tripod via 1/4" thread), the Drive+ N is a practical and cost-effective solution for multi-purpose professional video environments.
Key Features
- Full HD video up to 1080p60
- 12 optical zoom lens
- 1/2.8" 2.4MP CMOS sensor
- Simultaneous outputs NDIHX, HDMI, 3G-SDI, USB 3.0
- Supports SRT, RTMP, RTSP, ONVIF, VISCA protocols
- PoE+ (single cable power, video, and control)
- USB webcam functionality (plug-and-play)
- Wide 72° field of view (ideal for rooms and classrooms)
- Up to 128 preset positions
- RS232/RS485/USB control interfaces
- Tally light support for live production
- Flexible mounting (wall, ceiling, tripod)
Included Accessories
- Telycam Drive+ N 12X Camera
- Power cable
- RS232 control cable
- IR remote control
- User manual
Camera & Lens Specifications
- Sensor: 1/2.8" 2.4MP CMOS
- Optical Zoom: 12x
- Focal Length: 3.92 - 47.32 mm
- Aperture: F1.8 - F2.8
- Horizontal FOV: 72° - 6.3°
- Minimum Focus Distance: 1 m
- S/N Ratio: >50 dB
- Minimum Illumination: 0.7 lux
Video Output & Formats
- HDMI: Up to 1080p60
- 3G-SDI: Up to 1080p60
- USB 3.0: Up to 1080p60 (webcam mode supported)
- IP (NDIHX): Full HD streaming over network
- Codecs: H.264 / H.265
Streaming & Protocols
- Protocols: NDIHX, SRT, RTSP, RTMP, ONVIF, VISCA over IP
- Dual stream output supported
- Network: RJ45 Gigabit Ethernet
- Control: VISCA, Pelco-D/P, VISCA over IP
PTZ Movement
- Pan Range: -170° to +170°
- Tilt Range: -30° to +90°
- Pan Speed: 0.1° - 120°/s
- Tilt Speed: 0.1° - 120°/s
- Presets: Up to 128
- Accuracy: 0.1°
Image Processing
- WDR, Backlight Compensation
- 2D & 3D Noise Reduction
- Auto/Manual exposure, focus, iris
- White balance presets (auto/manual/one-push)
- Anti-flicker (50Hz/60Hz)
Power & Physical Specifications
- Power: DC 12V or PoE+ (IEEE 802.3at)
- Power Consumption: 10W
- Dimensions: 220 x 190 x 173 mm
- Weight: 1.35 kg
- Color: White
- Operating Temp: -10°C to 50°C
- Humidity: 20-80% RH
