The SKAARHOJ 1 M/E Mega Panel Lyra
The SKAARHOJ 1 M/E Mega Panel Lyra is a modular live-switching control solution designed for professional broadcast environments. Combining multiple control surfaces into a unified system, it delivers powerful customization, seamless integration with major switchers, and streamlined operation via Gigabit PoE connectivity.
This highly flexible and scalable live production control panel is built for demanding broadcast, streaming, and AV workflows. Designed as a modular 1 M/E (Mix Effect) system, the Lyra integrates multiple SKAARHOJ control surfaces into a cohesive and ergonomic panel, allowing operators to manage switching, routing, and device control from a single interface.
This configuration includes a T-Block Left module, two Master Key 48 modules, and a Quick Shot module, all mounted within a robust 1 M/E frame. Each module leverages SKAARHOJ's Blue Pill Inside technology, enabling deep customization and seamless communication with a wide range of third-party systems such as ATEM, vMix, TriCaster, Kairos, AMPP, and Carbonite.
The T-Block Left module provides advanced tactile control with 15 premium NKK buttons, 8 programmable four-way buttons with OLED displays, and a precision T-bar for transitions. The Master Key 48 modules add extensive switching capabilities with RGB multi-level metering LEDs and graphical OLED feedback, while the Quick Shot module enhances workflow efficiency with 28 programmable four-way RGB buttons for rapid source selection and macros.
All modules connect via Gigabit Ethernet with PoE support, simplifying installation by combining power and data into a single cable. Powered by skaarOS, the system allows full customization of layouts, functions, and device mappings, making it adaptable to virtually any production scenario.
Key Features
- Modular 1 M/E live-switching panel configuration
- Includes T-Block Left, 2 x Master Key 48, and Quick Shot modules
- Blue Pill Inside technology for advanced customization and control
- 24 crosspoints with dedicated transition module
- Programmable four-way buttons with OLED displays
- High-quality NKK buttons for professional tactile feedback
- Precision T-bar for smooth transitions
- RGB multi-level LED metering and graphical OLED feedback
- Works with major systems including ATEM, vMix, TriCaster, Kairos, and more
- Gigabit Ethernet with PoE for simplified setup
- Fully customizable via skaarOS
- SKAARHOJ 1 M/E Mega Panel Lyra
- T-Block Left Module (Blue Pill Inside)
- 2 x Master Key 48 Modules (Blue Pill Inside)
- Quick Shot Module (Blue Pill Inside)
- 1 M/E Frame Assembly
- Power supply (included)
- Display 11 x OLED, 1 x RGB LED bar
- Controls
- 8 x 4-way buttons
- 15 x NKK buttons
- 4 x encoders
- 1 x T-bar
- Connectivity
- 1 x RJ45 Ethernet (Gigabit PoE)
- 1 x Micro-USB
- Operating System skaarOS
- Power Source AC input / PoE
- DC Input Power 12 VDC
- Power Consumption 6.66 W
- Color Black
- Dimensions 10.7 x 6 x 4.8 (27.2 x 15.2 x 12.1 cm)
- Weight 2.7 lb (1240 g)
