DwarfConnection DC Link CLR1 WHDI Video Transmission System
Condition: New product
Goods are not available at the moment
We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.
MasterFoto.lv website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.
Or ask about:
DwarfConnection DC Link CLR1 WHDI Video Transmission System
The DC-Link-CLR1 is a high-performance WHDI video transmission system that can transmit uncompressed video and audio signals up to 250m with low latency (1 ms delay).
- Real-Time Transmission
- Uncompressed Transmission in 422 10-bit up to 1080p60 (3G-SDI & HDMI)
- 250m Range
- Compact design & durable Metal Casing
- Approved for indoor use
- Rapid and Reliable Connectivity
- Works in the License-free 5GHz ISM Frequency Band
Due to the decision not to implement the DFS System, the device has a longer range and better usability than comparable systems, but is only authorized for indoor use.
The system is compatible with the DC-Link-LR1 Video Transmission System. Four receivers can be used for every transmitter.
In the Box
- 1x Transmitter
- 1x Receiver
- 2x External Antennas
- 2x DC Adapter Cables
- 2x Power Supplies
- 1x Pro Clamp
- 1x Magic-Arm with 1/4 Screw
- 1x Hot Shoe Adapter
- 1x Slot Screwdriver
- 1x Quickstart Manual
- 1x Transport Case
Technical Data
- Transmitter
- 1x 3G/HD/SD-SDI Input
- 1x HDMI Input
- Frequency Range 5.1-5.9GHz
- Power 6.5 - 16.8V
- Power Consumption 6.5W
- Receiver
- 1x 3G/HD/SD-SDI Output
- 1x HDMI Output
- Video Formats
- SDI/HDMI 1080p, 1080i, 720p, 576i, 480i
- Audio
- SDI embedded Audio - 2 Channel (Ch1, Ch2) 48KHz/24bit
- Weight
- Transmitter 0.270kg
- Receiver 0.355kg
| Type of Product | Wireless Video Transmission Systems |
