Infinitek CAT5e Flexi drum 20 m

The Canare CAT5e Flexi drum features a flexible and robust Canare RJC5ES-4P-BS CAT5e STP network cable with a 6.7 mm outer diameter and Neutrik etherCON RJ45 terminations, wound on a Schill cable drum. This Ethernet cable is suitable for computer networks, digital audio networks, network cameras, and HDBaseT transmissions. The total cable length includes connectors.

Canare RJC5ES-4P-BS cable

Features

• Flexible and extra strong CAT5e STP cable for distances up to 50 m
• 1000BASE-T, 100BASE-TX and 10BASE-T compatible
• Stranded conductors with common shield braid
• Excellent flexibility and resistance to repeated bending

Specifications - High performance and high speed cable transmissions

• Standard manufactured lengths in (m): 100/200
• Cable weight in kg/100 m: 6.1
• Sheath diameter in mm: 6.7
• AWG: 24 (0.22 mm)
• Number and diameter of cores per conductor in mm: 7/0.20
• Shielding factor: 90
• Conductor resistance in ohms/100 m: 9.5
• Impedance in ohms: 44

Ethernet cable designation

CAT5e
U - unshielded
F - foiled
S - Shielded

RJ45 connectors Neutrik NE8MC

Specifications

• Name: NE8MC
• Type: Male
• Cable diameter: max. 8 mm
• Force required to connect: 20 N
• Force required to disconnect: 20 N
• Lifetime: > 1000 mating cycles

Material

• Cable cap: polyamide (PA 6)
• Body: zinc die-cast (ZnAl4Cu1)
• Body finish: nickel
• Temperature range: -30 C to +80 C

Drum Schill GT-235.RM

Application

• For various types of cables
• Plastic holder for cable fixing
• Capacity in (m) according to cable diameter: 5 mm - 109 m, 6 mm - 79 m, 7 mm - 61 m

Technical data - cable socket for cables included in the package

• Handle for easy winding
• Integrated brake
• Dimensions (width x depth x height) in mm: 208 x 206 x 295
• Weight in kg: 1.00
