Roland RUBIX22 2-in/2-out USB Audio Interface
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Audio Production Studio |
| Connector | USB-C + XLR |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
Studio-Grade Sound Quality
The Roland RUBIX22 is a portable 2-in/2-out USB audio interface delivering clean, detailed sound with transparent, low-noise microphone preamps. It supports high-resolution audio up to 24-bit/192kHz, ensuring professional-grade sound quality. Constructed from durable metal, its compact design features extensive shielding and ground lift switches to minimize noise and interference, providing clean audio in various recording environments.
Dual High-Quality Microphone Preamps
Equipped with two low-noise, high-definition mic preamps, the RUBIX22 captures detailed and dynamic recordings with ample headroom. The flexible combo XLR/TRS inputs allow connection of microphones, instruments, and line-level sources without adapters or special cables. One input features a Hi-Z mode for guitars and other high-impedance instruments.
Compatibility and Portability
The interface is designed for seamless operation with Mac, PC, and iPad devices. It features low-latency, class-compliant drivers for Windows and macOS, enabling smooth and reliable audio performance. Its compact size and USB bus power make it ideal for on-location recording, mobile production, and live performance setups.
Key Features
- 2-in/2-out USB audio interface with 24-bit/192kHz resolution
- Two low-noise mic preamps with XLR/TRS combo inputs and phantom power (+48V)
- Hi-Z input for guitar and high-impedance sources
- MIDI In/Out ports for external MIDI device connectivity
- Extensively shielded, low-noise metal construction
- Ground lift switches to reduce hum and noise in various venues
- Large, easy-to-read LED indicators for input levels, phantom power, and Hi-Z status
- Low latency, class-compliant USB drivers for Mac and PC
- Powered via USB bus or optional 5V DC supply
- Includes six months of Roland Cloud Pro membership with access to Zenbeats and software synthesizers
Technical Specifications
- System: 2-in/2-out audio interface
- Signal Processing: 24-bit AD/DA converters
- Sampling Rates: 44.1, 48, 96, 192 kHz
- Interface: Hi-Speed USB, MIDI In/Out
- Connectors:
- XLR inputs (balanced, phantom power +48V, max 6 mA)
- 1/4" TRS inputs (balanced, Hi-Z on input 1)
- 1/4" TRS outputs (impedance balanced)
- 1/4" stereo headphone jack
- MIDI In/Out ports
- USB Type B (audio), micro USB (DC 5V power)
- Controls: Sensitivity knobs, Hi-Z switch, 48V phantom power switch, output level, headphone level, power, monitor mix, ground lift switches
- Indicators: Input level meters (channels 1L, 2R), power, Hi-Z, phantom power
- Input Levels:
- XLR: -60 to -12 dBu nominal, +2 dBu max
- TRS: -44 to +4 dBu nominal, +18 dBu max
- Output Levels:
- TRS outputs: -6 dBu nominal, +8 dBu max
- Headphone output power: 20 mW + 20 mW into 47 Ω load
- Headroom: 14 dB
- Impedance:
- Inputs: XLR ≥4 kΩ, TRS ≥15 kΩ, Hi-Z ≥500 kΩ
- Outputs: TRS 2 kΩ, Headphones 47 Ω
- Noise Level: -94 dBu typical
- Dynamic Range: 104 dB (AD), 109 dB (DA)
- Power Supply: USB bus powered or DC 5V (500 mA)
- Operating Systems: Windows 7/8/8.1/10, macOS 10.10+, iOS 9+
- Dimensions: 145 x 165 x 46 mm
- Weight: 1.0 kg
- Included Accessories: USB cable, setup guide, safety leaflet
