Swit PB-S290S 290Wh Multi-Sockets Square Cine Battery
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Camera Batteries |
| Battery type | V-tipa baterijas |
| Barošana | ar akumulatoru vai no tīkla |
| Suitable for | ARRI ALEXA (general ARRI cameras) |
| Suitable for | ARRI ALEXA (general ARRI cameras) |
| Connections | D-tap and DC male |
| Battery Capacity, mAh | 290Wh |
| Battery Capacity, mAh | 20.1Ah |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
Overview
The SWIT PB-S290S is a high-capacity 290Wh (14.4V) V-Mount cine battery featuring multiple power outputs, 200W high-load performance, fast charging support, and an OLED status display. Compact yet powerful, it is ideal for long-duration ENG, cinema, and high-consumption camera setups.
Performance
The SWIT PB-S290S 290Wh Multi-Sockets Square Cine Battery is engineered for professional cinema and broadcast applications requiring extended runtime and high-load performance. With a rated voltage of 14.4V and a large 290Wh (20.1Ah) capacity, the PB-S290S can power standard ENG cameras for approximately 10 hours and ARRI ALEXA cameras for around 3.5 hours.
Built with 24 premium 18650 high-load Li-ion cells, the battery delivers a consistent 200W / 16A output even at 1% remaining capacity, ensuring reliable performance for power-hungry cameras and accessories. Compared to standard batteries, its high-load cells provide improved durability and longevity under sustained heavy output.
Features
The PB-S290S features four D-Tap outputs (each supporting 10A / 120W) and one USB 5V/2A output, allowing simultaneous powering of multiple on-camera devices such as monitors, wireless transmitters, and follow focus systems.
Fast charging capability supports up to 6A using SWIT PC-P461S or S-3812S chargers, reducing charging time by over 50%. The battery reaches 80% in approximately 2.5 hours and fully charges in about 3.8 hours.
An integrated OLED display provides real-time information including remaining capacity percentage, estimated runtime, and battery cycle count. The battery also supports viewfinder information display on SONY and RED cameras. Advanced protection circuitry safeguards against overcharge, over-discharge, short circuit, and temperature extremes, ensuring safe operation and extended service life.
Compact and shorter than standard V/Gold mount batteries, the PB-S290S fits seamlessly on most professional camera rigs.
Key Features
- 290Wh / 20.1Ah high-capacity V-Mount battery
- 14.4V nominal voltage
- High-load 200W / 16A output (stable even at 1%)
- Powers ENG cameras for 10 hours, ARRI ALEXA for 3.5 hours
- 4 D-Tap outputs (120W / 10A each)
- 1 USB output (5V / 2A, 10W)
- OLED display for capacity, runtime, and cycle count
- Fast charging (6A supported)
- 80% charge in 2.5 hours; full charge in 3.8 hours
- High-grade 18650 Li-ion cells (24 cells)
- Advanced multi-circuit protection system
- Compact square design for better camera fit
Specifications
Electrical
- Voltage: 14.4V
- Capacity: 290Wh / 20.1Ah
- Max Output Power: 200W
- Max Output Current: 16A
- D-Tap Outputs: 4 (120W / 10A each)
- USB Output: 1 (5V / 2A, 10W)
Charging
- Fast Charge Support: 6A
- 80% Charging Time: Approx. 2.5 hours
- Full Charging Time: Approx. 3.8 hours
- Charging Temperature: 0°C to 40°C
Environmental
- Discharge Temperature: -20°C to 50°C (Performance may decrease below 0°C)
Physical
- Mount Type: V-Mount
- Dimensions: 12.1 x 9.5 x 9.6 cm
- Weight: 1.44 kg
- Display: OLED Screen
