Swit TD-R210A 500W Adapter
AI ASSISTANT CHAT
Or ask about:
| Type of Product | Battery Adapter Plate |
| Battery type | Gold mount |
| Barošana | ar akumulatoru vai no tīkla |
| Suitable for | ARRI SkyPanel/Orbiter |
| Suitable for | ARRI Orbiter / SkyPanel S60/S120 |
| Connections | D-tap and DC male |
| Battery Capacity, mAh | 5000 |
- 1. Evaluate your options.
- 2a. If you want to buy only one product with Aizdevums.lv leasing, then fill out the application here
- 2b. If you want to buy several items or use another leasing company, then put the items in the basket and choose the leasing service when ordering.
We offer leasing from Aizdevums SIA, Incredit SIA, ESTO.
Manager will check the availability of the items in the cart and send the loan application link. - 3. If you receive a positive response, contact us to purchase the product. Consultants will check the availability of the product.
- 4. If the product is available in the store or to be ordered from the warehouse, and you have received an affirmative answer from our consultants, please visit the store to proceed with purchase and leasing documents.
- 4a. You can also ask us to issue an invoice for this product and visit one of the leasing company branches to sign up leasing documents *..
- 5. Once the leasing documents have been signed up, you can receive the product in the store, if it is on site or inform our consultants and they will order it for you from the warehouse.
- *It is possible to arrange delivery for leased goods, so you can also perform the entire purchase process remotely.
**The sequence of leasing steps is the same for leases offered by InCredit Group.
***In case of doubt, contact our consultants!
When using leasing services, carefully evaluate your options to repay the loan!Lease
SWIT TD-R210A Overview
The SWIT TD-R210A is a high-load dual Gold Mount battery adapter delivering regulated 24V (240W) or 48V (up to 500W) output for high-power cinema lights. Designed for stand mounting, it features Neutrik XLR connectors and provides a portable power solution for fixtures such as ARRI Orbiter and SkyPanel S60/S120.
Performance
The SWIT TD-R210A is a professional 500W high-load battery adapter engineered to power demanding 24V and 48V cinema lighting fixtures using just two Gold Mount batteries. Designed for flexibility and portability, it provides regulated high-voltage DC outputs while maintaining stable and reliable performance on set.
High-power cinema lights often require 24V or 48V input to achieve full brightness. The TD-R210A enables this by combining two compatible high-load batteries to deliver:
- 24V regulated output (4-pin XLR) up to 240W
- 48V regulated output (3-pin XLR) up to 500W
Optimized for ARRI High-Power Fixtures
The ARRI Orbiter and ARRI SkyPanel S60-C / ARRI SkyPanel S120-C require 48V DC input to reach 100% light output and can draw over 400W. When paired with dual-voltage batteries such as the SWIT PB-H260A, the TD-R210A delivers a stable 48V, 500W output, enabling full-performance lighting in mobile or remote environments.
Reliable & Secure Connectivity
The adapter utilizes Neutrik 3-pin and 4-pin XLR connectors to ensure safe, stable high-current transmission. Its design allows mounting onto 2545mm light stands or C-stands, making it ideal for studio grids and location lighting setups.
Compact, portable, and engineered for high-output performance, the TD-R210A is a powerful battery-driven solution for professional broadcast and cinema productions.
Key Features
- Dual Gold Mount battery installation
- Regulated 24V (240W max) and 48V (500W max) outputs
- Designed for high-power cinema projectors and LED lights
- Compatible with ARRI Orbiter & SkyPanel S60/S120 (48V full output)
- Neutrik 3-pin & 4-pin XLR connectors
- Mounts to 2545mm light stands / C-stands
- Portable high-voltage battery power solution
- SWIT TD-R210A Dual Gold Mount 48V/24V Adapter
- Battery Mount 2 Gold Mount
- 24V Output 4-pin XLR, regulated, max 240W
- 48V Output 3-pin XLR, regulated, max 500W
- Maximum Power 500W (with compatible dual-voltage batteries)
- Connectors Neutrik XLR (3-pin & 4-pin)
- Mounting 2545mm light stand compatible
