Desview R72 7 4K HDMI Touchscreen Monitor DES-R7II

Desview vieglais R72 7" kamerā iebūvētais 4K HDMI skārienjūtīgais ekrāns nodrošina profesionālu uzraudzību ar asu 7" IPS LCD displeju ar 1920 x 1200 izšķirtspēju, atjauninātu 2600 cd/m² spilgtumu, 1100:1 kontrasta attiecību un skārienjūtīgo ekrānu, kā arī izvēlnes riteni. Atjauninātais spilgtums vēl vairāk atvieglo skaidru kadru apskati spilgtas saules gaismas apstākļos.

Ekrāna bloķēšanas poga novērš nejaušu iestatījumu maiņu no skārienekrāna. IPS LED panelim ir redzamības leņķis 178° L/R, U/D, kas nodrošina labas krāsas un kontrastu, pat skatoties ārpus ass, un tas attēlo 90 % DCI-P3 standarta. Monitoram ir HDMI ieeja un izeja, un tas atbalsta līdz pat DCI un UHD 4K video ieeju un caurlaides izeju.

R72 tiek darbināts, izmantojot integrēto L sērijas akumulatora plāksni vai atsevišķi pieejamo līdzstrāvas adapteri. USB ports ļauj importēt pielāgotus 3D LUT. Divi 1/4"-20 vītnes (sānos un apakšā) ļauj monitoru piestiprināt pie dažādām konfigurācijām vai arī varat izmantot komplektā iekļauto aukstās kurpes adapteri, lai monitoru piestiprinātu pie kameras. 3,5 mm austiņu ligzda ļauj pārraudzīt iebūvēto audio.

Funkcijas

• Dienas gaismā redzams 7" skārienjūtīgais ekrāns kamerā ar 2600 cd/m² spilgtumu.
• Tievs, viegls dizains ar skārienjūtīgo IPS LCD paneli.
• HDMI atbalsta video ievadi līdz DCI 4K24/UHD 4K30.
• Divi 1/4"-20 montāžas vītnes monitora augšpusē un apakšpusē.

Skārienjūtīgais ekrāns

• R72 monitoram ir 7" skārienjūtīgais ekrāna panelis ar 1920 x 1200 izšķirtspēju un 16:10 malu attiecībām. Pieskaroties ekrānam ar vienu pirkstu, var kontrolēt visu monitoru, un tas atbalsta tādus žestus kā piespiešana, lai palielinātu, kas palīdz pārbaudīt katru attēla stūri un detaļu. Īsi nospiežot ieslēgšanas pogu, ekrānu var bloķēt, lai novērstu nejaušas izmaiņas jūsu izvēlēs.
• Augstais 2600 cd/m² spilgtums nodrošina skaidru displeja attēlu pat filmējot spilgtā ārējā vidē.

Displeja rīki

Pikseļu attēla palielināšana ar saspiešanu
Aspekta attiecība: Iepriekš iestatīti un pielāgojami
Anamorfiskā samazināšana: 1,33x, 1,5x, 1,66x, 1,79x, 2,0x
Attēla apgriešana: Automātiska un manuāla
Attēla pagriešana: Automātiska un manuāla
Krāsu fokusa palīgs ar regulējamu stilu un intensitāti
Spīķēšanas funkcija ar regulējamu intensitāti
Viltus krāsas
Zebra, pielāgojama
Viļņu forma: Luma un RGB, pielāgojama ar interešu reģiona izcelšanu
Vectorscope
RGB parāde, pielāgojama
Histogramma: Luma un RGB
LUT importēšana, izmantojot USB atmiņas ierīci
Audio mērītāja displejs

The lightweight R72 7" On-Camera 4K HDMI Touchscreen Monitor from Desview provides professional monitoring in a sharp 7" IPS LCD with 1920 x 1200 resolution, an updated 2600 cd/m² brightness, 1100:1 contrast ratio, and touchscreen control, along with a menu scroll wheel. The updated brightness makes it even easier to view your footage clearly in bright sunlight conditions.

A lock screen button prevents accidental changes to your settings from the touchscreen. The IPS LED panel has a viewing angle of 178° L/R, U/D for good color and contrast, even with off-axis viewing, and it displays 90% of the DCI-P3 standard. The monitor features HDMI input and output, and it supports up to DCI and UHD 4K video input and pass-through output.

The R72 is powered using the integrated L-series battery plate or via a separately available DC adapter. A USB slot allows you to import custom 3D LUTs. Two 1/4"-20 threads (side and bottom) allow you to mount the monitor on a variety of configurations, or you can use the included cold shoe adapter to mount the monitor on your camera. The 3.5mm headphone jack allows you to monitor the embedded audio.

The Desview R7II is the ideal solution for those looking for a large preview monitor whose size and weight still allow the device to be ergonomically connected to a camera, cage or "magic arm" mount. The 7" touch screen features 2 1/4" threads for vertical or horizontal installation. The monitor is equipped with HDMI 1.4 output and input, allowing to transmit a signal with a maximum resolution of 4K. This model is distinguished by its outstanding brightness (2600 nits). On board there are useful tools to facilitate image control ( including False Color, Histogram and Zebra), support for 3D LUT color profiles and HDR mode. The device can be powered by a power supply or rechargeable batteries (NP-F or V-Mount). Main Product Features 7-inch preview monitor Above-average screen brightness - 2600 nits IPS touchscreen with gesture support for easy use 3 power options - power adapter (DC 7 - 24V), NP-F battery or V-Mount battery (D-Tap cable included) native resolution - FullHD compatible with the color range defined in the REC.709 standard supports 3D LUT tables (you can upload your own presets or use pre-defined color profiles) offers signal transmission of up to 4K resolution equipped with HDMI 1.4 output and input includes HDMI / micro HDMI and HDMI / mini HDMI cable 2 programmable shortcut buttons (can be assigned the most frequently used functions) cold shoe mount included (convenient installation on camera or mount) 2 female 1/4" threads for vertical or horizontal monitor installation 3.5mm mini jack headphone output USB-A port for software updates and LUT uploads tools for easy control of the captured image (False Color, Single Color, Histogram, Vectroscope, Waveform, Zebra, Peaking) support for various aspect ratios (including anamorphic image) adjustment of image brightness, contrast, sharpness and saturation grids, screen markers and safe area also included: monitor case, microfiber cloth, Allen wrench and USB flash drive Large and bright screen The large touchscreen offered by the Desview R7II is an excellent choice for those who are not satisfied with the popular 5.5" monitors used when recording video footage. Thanks to it, you won't miss a single detail! The 7-inch display also provides above-average brightness, which is 2600 nits. Such parameters will provide adequate comfort even when you come to film in bright sunlight. Compliance with the color range defined in the REC.709 standard will ensure that the image viewed on the monitor will never be skewed against the original recording! Touch support The IPS display provides full touch operation of the device. Such a solution guarantees fast and convenient control of settings. Cooperation with popular gestures used in touch interfaces will allow you to, among other things, conveniently zoom in or out, adjust the volume, and change the brightness of the backlight. All this will further facilitate the control of recorded shots and quick switching between different parts of the menu. There are also 2 programmable shortcut buttons on the top of the monitor, to which you can assign the most frequently used functions. Signal quality 4K The Desview R7II features both HDMI 1.4 input and HDMI 1.4 output, giving you even more freedom to work with video devices. The preview monitor can easily handle up to 4K resolution signal transmission. Thanks to the 3.5mm mini jack headphone connector, you will also gain the ability to monitor audio in real time. This is an ideal solution for both professionals and home video makers who want flexibility and convenient control of the recorded material. Convenient power supply The Desview R7II preview monitor will work well both in the studio and outdoors. This is because the device supports a variety of power supply methods. If you have an electrical outlet nearby, reach for an AC adapter. And when you're working outdoors or want to avoid tangled cables, use an NP-F battery pack (NP-F550, NP-F750 or NP-F970). You will plug the cell into a special socket with a solid locking mechanism. You will also find a D-Tap cable included with the monitor, which will allow you to connect the device to a V-Mount battery pack. Power supply or batteries MUST be purchased separately. HDR mode Want to make the image displayed on your monitor even more detailed? Take advantage of HDR (High Dynamic Range) technology, which makes whites whiter and blacks even deeper! High dynamic range also means greater brightness, contrast and more vivid colors. With the HDR function, the Desview preview monitor will allow you to render the full scale of contrasts and enjoy an even more realistic image. Private color profiles The Desview R7II preview monitor allows you to use 3D color tables. This means that already at the recording stage you will apply so-called LUTs, effects that can be compared to filters, which are responsible for color correction of video images. The device has its own library of ready-made presets, but the possibilities of the Desview R7II do not end there. You can plug the included flash drive into a USB port and upload your own LUTs to the device, which will allow you to test a professional "film look" on the preview or experiment with unique image styling, even before you start the editing and post-production stages. Perfect-frames Working with the Desview R7II preview monitor will help you set up your frames with precision. The device allows you to use the center markers of the frame ("Center Mark") and the safe area ("Safe Area"). Among the available tools, there is also a grid that can be superimposed on the preview. The monitor also offers support for different anamorphic aspect ratios. The feature will enable comfortable work with custom lenses to achieve an even more cinematic "movie look." Exposure control The Desview R7II preview monitor offers a number of tools to help you better evaluate exposure levels while working with your camera or camcorder. Using the "Zebra", "False Color" and "Single Color" modes, you can easily determine which elements of the frame are too bright and which are too dark. These tools will come in handy wherever poor lighting conditions prevent you from accurately assessing the exposure of, among other things, the skin or faces of the filmed characters. Anamorphic image The Desview R7II preview monitor offers support for various anamorphic aspect ratios (1.33x, 1.5x, 1.66x, 1.79x and 2.0x). The feature will enable comfortable operation with custom lenses to achieve an even more cinematic "movie look." After selecting the appropriate aspect ratio, the image will be displayed on the monitor screen after "desqueeze" editing, with the appropriate framing frames. Additional accessories Included with the Desview R7II monitor, you'll find a number of useful accessories that will make your preview work easier. HDMI cables will allow you to connect the device to various models of cameras and camcorders (mini HDMI and micro HDMI), providing fast transfer of high-quality images. The cold shoe mount will allow convenient work when the monitor is attached to the body, cage or "magic arm" mount. A USB flash drive will provide convenient transfer of custom LUTs directly to the monitor or software updates. Also included is a microfiber cloth and a nice-to-touch carrying case. Specification model: Desview R7II screen: 7" (IPS) resolution: fullHD (1920 x 1200) color gamut: 95% NTSC (Rec.709) screen aspect ratio: 16:10 contrast ratio: 1000:1 pixel density: 403 PPI brightness: 2600 nits viewing angle: 178º Ports: DC input HDMI 1.4 output HDMI 1.4 input USB-A port mini Jack 3.5mm HDMI input signal format: 720×480i / 720×480p @ 59.94, 60Hz 720 x 576i / 720 x 576p @ 50Hz 1280 x 720p @ 50, 59.94, 60 HZ 1920 x 1080i @ 50, 59.94, 60 Hz 1920 x 1080psf @ 23.98, 24, 25, 29.97, 30 Hz 1920 x 1080p @ 23.98, 24, 25, 29.97, 30.50, 59.94, 60 Hz 3840 x 2160p @ 24, 25, 30 Hz 4096 x 2160p @ 24 Hz HDMI output signal format: 720×480i / 720×480p @ 59.94, 60Hz 720 x 576i / 720 x 576p @ 50Hz 1280 x 720p @ 50, 59.94, 60 HZ 1920 x 1080i @ 50, 59.94, 60 Hz 1920 x 1080psf @ 23.98, 24, 25, 29.97, 30 Hz 1920 x 1080p @ 23.98, 24, 25, 29.97, 30.50, 59.94, 60 Hz 3840 x 2160p @ 24, 25, 30 Hz 4096 x 2160p @ 24 Hz Voltage: 7 - 24 volts power consumption: ≤ 14 W dimensions: 178 x 117 x 22.2 mm weight: 380 g Kit contents Desview R7II preview monitor HDMI / micro HDMI cable HDMI / mini HDMI cable D-Tap cable cold shoe mount USB flash drive protective case Allen wrench microfiber cloth
