Canare L-3C2VS GRN BNC 20m CV-3-M/M-GRN-20

Rated 4.7/5 based on 11 customer reviews

3845 ar PVN

Piegādes laiks parasti 5 - 12 darba dienas

18876
CV-3-M/M-GRN-20
0000000000000
Canare

Jauns

05.04 - 21.04.2024
Saņemt veikalā
Bezmaksas
06.04 - 22.04.2024
Pakomāts (Omniva, DPD, Venipak)
3 €
06.04 - 22.04.2024
Kurjers (DPD, Omniva)
no 10 €
05.04 - 21.04.2024
Velokurjers (tikai Rīga)
no 7 €

Oriģinālais preces apraksts no ražotāja (oriģinālā valodā)

CanareL-3C2VS GRN BNC(M-male) / BNC (M-male)20m

Canare L-3C2VS is a very lightweight and extremely flexible 5.5 mm HD/SD-SDI coaxial cable with a braided center conductor and a tightly woven shielded outer conductor. The L-3C2VS cable remains flexible even at low temperatures. Both ends have crimp-on BNC (M) connectors type BCP-A3.

Application:

  • HD/SD-SDI video
  • PAL and NTSC analog video
  • Satellite applications
  • TELCO
  • Test equipment
  • Rack cabling
  • Patch cables for video

Cable Specifications:

  • Sheath diameter (overall diameter) in mm: 5.5
  • Cable weight in kg/100 m: 4.5
  • Medium conductor - number and diameter of cores in mm: 7/0.18
  • Total diameter of the middle conductor in mm: 0.54
  • Foam dielectric - diameter in mm: 3.1
  • Resistance of the middle conductor in ohms/100 m: 10.5
  • Resistance of the outer conductor in Ohm/100m: 1.9
  • Static capacitance in pF/m: 67
  • Attenuation in dB/100m: 4.5
  • Impedance in ohms: 75

Connector specifications: - mains connector, - mains connector:

  • Tensile strength in kg: >24.9
  • Insulation resistance at 500 V DC in Ohms: 24.5 mm: >1000M
  • Rated voltage for 1 min: 1500 V AC (effective value)
  • Center contact resistance: 1.5 mm: <6m ohms
  • External contact resistance: contact strength: <3m ohm
  • Impedance in ohms: 75
  • Connector body - material/surface : brass/nickel
  • Center contact - material/surface: brass/gold
  • Outer contact - material : Beryllium copper
  • Dielectric - material : Material - polytetrafluoroethylene PTFE
  • Crimp sleeve - material/surface: copper/tin

Maximum transmission distance depending on video format
Data transfer rate143 Mbps177 Mbps270 Mbps360 Mbps540 Mbps1.5 Gbps
SpecificationsSMPTE 259MITU-R BT.601SMPTE 259MSMPTE 259MSMPTE 344MSMPTE 292M
UseComposite NTSCComposite PALComposite 4:2:2Component 4:2:2 16x9SDIHD-SDI
Modelmmmmmm
L-3C2VS24121817415012046
